7. Compact Flash (CF) Card

The Logicube SuperSonix comes with a Compact
Flash (CF) Drive that is inserted in a CF slot at the
bottom of the unit. This drive is used for loading
software on the Logicube SuperSonix but it can
also store Debug Log Trace Reports for
troubleshooting purposes.
NOTE: Please check our website periodically at
www.logicube.com, any new CF functions will be
posted there.
To load new software from the CF Drive, please
refer to the procedure "Loading Software Using
the Compact Flash" which is found in Chapter 8:
Software loading Instructions.

Inserting and Removing the Compact Flash

Please refer to Figure 24 below.
1. At the bottom of the Logicube SuperSonix is
a Compact Flash (CF) slot. Make sure that
it is clear.
2. Hold the CF Drive so that the Logicube label
faces up.
3. Slide the CF Drive into the CF slot. As it
slides into place, the eject button will slide
out.
4. To remove the CF Drive, simply press in the
eject button. The drive will slide out.
