4. Modify the other Setting preferences –
5. Tap the Start
6. The Logicube SuperSonix will notify you

Scan Target Mode

Scan Target mode scans the Target drive for weak
and bad data sectors. It uses the Read-Verify
command of the ATA specification to detect bad or
weak spots on the Target drive. When a suspect
area of the drive is detected, a sector-by-sector
analysis is performed.
If a given sector is read incorrectly one or more
times out of 10 tries, it is considered to be weak. If it
is read incorrectly 10 times out of 10, it is
considered to be bad.
Any drive that shows weak sectors should be
returned to the manufacturer or retired due to the
higher risk of potential data loss.
When using Scan Target mode, there are two levels
of scanning speed to choose from:
• Fast (Default) – This is the fastest.
• Thorough – This is the most thorough level and
provides the most detailed scan of the drive.
Important Note: The Thorough operation writes
patterns to some sectors, which can cause data
corruption. Use this setting only when data loss is
not an issue.
back icon. The SuperSonix will now perform
the action you've selected whenever an
Error is encountered during cloning.
Mode, Verify, Direction, CHS Mode, and
Speed - as needed.
icon. The cloning
operation will begin and a status screen will
appear.
when cloning is complete. Tap the Back icon
to return to the main menu.
