CLONING MODES AND SETTINGS

About Screen

Wizard Mode

26
5. To verify the cloned target drive matches the
Master drive tap the Verify Target Drive
icon.
Verify Target Drive
Calculates the MD5 Hash of the cloned Target
drive and compares it to the hash value previously
stored on the CF. Once the process is complete
the SuperSonix will display both values and also
indicate if there is a match.
MD5 Verification Results for (Model: WDC
WD3201ABYS-01B9A0, Serial
WD-WCARW3590618):
MD5 Verified SUCCESSFULLY!
calculated MD5: 1368 06C7 231D DF0F A2B6 8B45
AA68 D983
expected MD5: 1368 06C7 231D DF0F A2B6 8B45 AA68
D983
number of sectors calculated: 100
Select the About Screen icon to view information
about the SuperSonix. The serial number of your
unit along with the software and firmware versions
currently loaded will be displayed. The About
screen also lists all options currently enabled on the
unit and provides contact information for Logicube
Technical Support.
To return to the main menu, simply tap the OK icon
at any time.
This menu provides a list of automated actions.
Current SuperSonix Wizards will automatically
handle (Non - FAT, FAT32 & NTFS) and all FAT,
FAT32 or NTFS partition cloning with limited user
interaction. See the Getting Started section for
Wizard Mode instructions.
