OPTIONAL PERIPHERALS

Logicube SAS Adapter

54
6. Make all the necessary settings on your
Do not use one of the SuperSonix included
PATA drive cables. They are incompatible
with the CloneCard Pro!
7. Set the Speed setting to PIO-Medium. No
8. Press the START icon and wait for the

Improving Speed of Transfer

Several settings in the CMOS setup screens can potentially improve
the speed of transfer.
PCI latency timer - Try to reduce the value of this
number as much as possible.
PCI write buffer - Set to enable to improve writing
speed to the local drive.
PCI zero-wait states - Enable to decrease PCI
cycle time.
PCI delay transaction - Disable to decrease PCI
cycle time.
PCI dynamic bursting - Set to yes.
Enable 32-bit access to hard drive - We test for
that, and if available, we use it to improve transfer
speed, so no action is required on behalf of the
user.
NOTE: Some of these settings may not be present
on your machine. Also, some of these settings may
cause other peripherals to not function properly, so
use with caution, and always change one setting at
a time.
The SAS Adapter is designed to attach directly to
the Logicube SuperSonix. Functionally the adapter
allows for external connection and Mirror cloning of
SAS & USB connected master drives to internal
IDE or SATA drives through the IDE port of the
SuperSonix.
NOTE: USB cloning capability is Optional and this
type of clone is always performed outside to inside.
SuperSonix.
settings are available on the client program.
process to complete.
Logicube SuperSonix User's Manual
