OPTIONAL PERIPHERALS
56
Use the power port closest to the ribbon
cable.

Cloning with the SAS Adapter

Duplicating SAS to SATA or IDE

To clone a SAS drive connect one side of cable
CBL-SAS-001-A to the SAS hard disk drive and
plug the other side (which splits and forms the
shape of a 'Y') into the SAS data and power ports
located on the SAS adapter above the label
MASTER and proceed to step 1.
1. Install a SATA or IDE hard drive inside the
NOTE: For 100% Mirror clones the target drive
should be at least as large as the drive to be
captured.
2. Insert the power supply cord to turn on the
3. At this point you can perform a drive info
4. Perform a normal Outside to Inside Mirror
NOTE: Ensure that the Mirror clone Direction is set
to T->M or the clone process will error out.
NOTE: Capture from HPA and DCO areas are not
supported.
NOTE: Master Manager, Selective Partitions,
WipeClean, Repair and CleverCopy are not
currently supported.
NOTE: Cloning data to a SAS drive in the Master
position is not supported.
Logicube SuperSonix as defined in section 2
Getting Started.
Logicube SuperSonix. The LED located on
top of the SAS adapter near the RESET
button will illuminate green indicating the
adapter is receiving power correctly.
check to verify that the SuperSonix
recognizes the SAS drive connected through
the SAS adapter.
Clone by following the Step-by-Step Mirror
mode instructions under CLONING MODES
AND SETTINGS.
