OPTIONAL PERIPHERALS
58
3. You can perform a drive info check to verify
that the SuperSonix recognizes either of the
SAS drives connected through the SAS
adapter. Press the SAS Drive Info icon and
select one of Tap two drive choices shown in
Figure 16.
Figure 16.
4. Tap the SAS to SAS Mirror icon
shown in Fig. 15 to proceed with a SAS to
SAS Mirror clone. Two icons like to ones in
Figure 17 will be displayed.
Figure 17.
5. Tap the Percentage icon
percentage of the Master drive to clone. Use
the electronic keypad to adjust the value
between 1 and 100% and press <OK>.
NOTE: A
will appear asking: Do you want to set to
XX% mirror copy?
6. Tap <YES> to set the percentage to the
requested value.
7. Tap (Start) to begin the cloning
process.

Hashing SAS Master and Target Drives

To calculate the MD5 Hash of a Master drive
and compare it to the Hash value of a cloned
Target drive perform the following:
Logicube SuperSonix User's Manual
to change the
User Attention Required message
