A: Technical Specifications

Environmental Specifications

Optional Solid State Disk Parameters

56
Table A-2 lists the environmental specifications of the system.
Table A-2 Environmental Specifications
Feature
Temperature tolerance
(operating)
Temperature tolerance
(non-operating)
Relative humidity
Cooling requirement
Maximum altitude
Table A-3 shows the basic operating parameters of the optional solid state disks available with the
Octane III systems. Note that MLC drives used beyond the capacity of their total projected write
life will not be replaced under warranty. STEC drives are warranted for three years regardless of
the number of writes. Both the MLC and STEC drives use a volatile write cache and are subject
to data loss during a power failure; this could cause XFS file system corruption and require file
repairs.
Table A-3 Solid State Disk (SSD) Operating Parameters
SSD type Drive capacity
Intel MLC 80 GB
Intel MLC 160 GB
STEC 60 GB
Mach8
Specification
+5 °C (41 °F) to +35 °C (95 °F) (up to 1500 m / 5000 ft.)
+5 °C (41 °F) to +30 °C (86 °F) (1500 m to 3000 m /5000 ft. to 10,000 ft.)
-40 °C (-40 °F) to +60 °C (140 °F)
10% to 80% operating (no condensation)
8% to 95% non-operating (no condensation)
Ambient air
10,000 ft. (3,049 m) operating
40,000 ft. (12,195 m) non-operating
Write size Program/erase cycles
4 KB average 2,500 lifetime minimum
4 KB average 2,500 lifetime minimum
Variable 100,000 minimum over the
life of the drive
Projected write life
7.5 TB
15 TB
Unlimited writes over
three years
007-5633-001
