1: System Quick Start and Overview

Choosing a Site

4
The Silicon Graphics Octane III cluster server operates reliably within normal air conditioned
office or lab environments. Select a site that meets these criteria:
• Near two properly earthed, grounded, three-pronged power outlets, as follows:
– In the U.S. and Canada: two single-phase NEMA 5-15R outlets for 100-120 V.
Connectors will differ for 200-240 V applications.
– In other geographic areas: a properly earthed, grounded outlet in accordance with the
local electrical authorities and electrical code of the region.
Note: Optional external drives connected to the Octane III will require a separate power
source to operate.
• Clean and relatively free of excess dust.
• Well-ventilated and away from sources of heat, with the ventilation openings on the system
kept free of obstructions.
• Away from sources of vibration or physical shock.
• Isolated from strong electromagnetic fields and line noise caused by electrical devices such
as elevators, copy machines, air conditioners, large fans, large electric motors, radio and TV
transmitters, and high-frequency security devices.
• Access space provided so the power cords can be unplugged from the power supply or the
wall outlet. This is the only way to remove AC power from the system.
• Clearance provided for cooling and airflow.
Note: In regions that are susceptible to electrical storms, it is recommended that you plug
your system into a surge suppressor and disconnect any telecommunication lines during
electrical storms.
007-5633-001
