Antenna Dimension
The method of installation and mounting of antenna may vary with
vessel design but the following procedures are applicable in most
situations, and will result in a secure and effective installation. Confirm
the height and diameter the antenna before installing it.
151.7cm
(59.7")
Ø146.8cm
(57.8")
Figure 12. Radome Dimension
14 V110 – Marine Satellite Communication System
