TX MUTE ACTIVE
▲ ▼
LOW
Antenna Control Unit
9. Set TX MUTE ACTIVE
A transmit inhibit out put from the ACU will disable/mute the modem transmit via a
voltage whenever the antenna is blocked, searching, or is mis-pointed 0.5 degrees from
peak satellite position. This setting can be varied from modem to modem. (Refer to the
modem manual for details.)
Press UP and DOWN arrow keys to select HIGH or LOW. Press OK key to set the
parameter. Press RETURN key to select the parameter you wish to edit and press
RETURN key again to save or abort and return to the main display.
STEP SIZE ELEVATION
▲ 00.0 ▼
# 0.2 #
Antenna Control Unit
10. Set TILT BIAS OFFSET
The tilt bias is required to set when the control board, skew potentiometer or belt is
replaced. Check and see if the bubble is in the center of the circular bubble level vial .
If not, press OK key to enter TILT BIAS menu to adjust elevation and cross-level
angles.
Press NUMBER keys to set the step size. Press LEFT and RIGHT arrow keys to
move CROSS LEVEL OFFSET by step size. Press UP and DOW N arrow keys to
move ELEVATION OFFSET by step size. Press RETURN key to save or abort and
return to the main display.
M
+TILT BIAS
R
F
M
CROSS LEVEL
◀ 01.0 ▶ R
F
Operating the ACU
1 2 3 ←
4 5 6 0
OK
·
7 8 9
1 2 3 ←
4 5 6 0
OK
·
7 8 9
