Preparing the Installation

Unpack the v110 box
The antenna pedestal is shipped completely assembled in its radome.
Remove the four shipping blots which mount the antenna to the pallet.
The pallet should be lifted by means of suitable sized lifting equipment.
(Refer to the supplied instruction guide for details on how to unpack
wooden crate of v110.)
19mm Spanner
Figure 11. Remove 4 bolts from the bottom of the box
Installing the Antenna
