LOAD ?
→ YES
Antenna Control Unit
7. Press RETURN key to load the current setting or abort and return to the main
display.
LOADING . . .
DO NOT TURN OFF !
Antenna Control Unit
8. Setting is being loaded to the system.
The ACU will restart the system automatically after uploading the setting.
DO NOT TURN OFF ACU POWER while uploading is being processed.
TRACKING 113.0E KOREA_5
AZ:202.7( 202.7)
Antenna Control Unit
9. Antenna information has been updated.
NO
●●●○○○○○○○○○○○○
SIG:301
VL
EL: 48.3
SK:-72.0 Fn
Operating the ACU
1
2
3
M
R
4
5
6
0
OK
·
7
8
9
F
1
2
3
M
4
5
6
0
R
OK
·
7
8
9
F
1
2
3
M
4
5
6
0
R
OK
·
7
8
9
F
37
