Preparing Antenna Supporting Pole
Base Panel (10t)
Figure 15. Recommended Dimension of Mounting Pole
WARNING: Ensure that cables have been run through watertight fittings to
prevent water entry into the vessel when the installation is
completed. The coax cables must be inserted through the cable
strain relief(s) at the base of the radome.
16 V110 – Marine Satellite Communication System
200 (7.8")
Cable Entry
Unit: mm/inch
