Antenna Settings

Manual Search
SETUP MODE ?
→ YES
Antenna Control Unit
1. Press LEFT key to move cursor to YES and press OK key to enter setup mode.
→+ANTENNA
+SYSTEM
Antenna Control Unit
2. Press OK key to enter ANTENNA menu.
→
+MANUAL SEARCH
◀
+SEARCH PARAM
Antenna Control Unit
3. Press OK key to enter MANUAL SEARCH menu.
STEP SIZE AZIMUTH
00.2 # ◀ 231.7▶
#
Antenna Control Unit
4. Current IF signal level (AGC) / (SIG) is displayed to assist you in manually peaking EL
for best signal level. Press NUMBER key to change the step size. (Range : 0.1~99.9)
Press LEFT and RIGHT arrow keys to move azimuth by step size. (Range : 0~360)
Press UP and DOWN arrow keys to move elevation by step size. (Range : 0~90)
Press FUNCTION key to save current value or abort and return to the main display.
SAVE CURRENT SAT INFO?
→ YES
Antenna Control Unit
5. If the current settings are able to locate the satellite, press FUNCTION key to save
"current satellite information". It will shorten the satellite acquisition time next time.
Press LEFT key to move cursor to YES and press the OK key to save the settings.
38 V110 – Marine Satellite Communication System
NO
+SATELLITE
+INSTALLATION
+SET SKEW
▶
+SET PARAMETERS
ELEVATION AGC
▲ 48.3 ▼
301 Fn
NO
1 2 3 ←
M
4 5 6 0
R
OK
·
7 8 9
F
M 1 2 3 ←
4 5 6 0
R
OK
·
F 7 8 9
1 2 3 ←
M
4 5 6 0
R
OK
·
7 8 9
F
1 2 3 ←
M
4 5 6 0
R
OK
·
7 8 9
F
1 2 3 ←
M
4 5 6 0
R
OK
·
7 8 9
F
