User's Manual
GLI 350xi and ADA 2/GLI 350xi
Ground Loop Isolator and RGBHV Distribution
Amplifier with Ground Loop Isolator
68-1445-01 Rev. B
11 07
Advertisement
Table of Contents
Related Manuals for Extron electronics ADA 2/GLI 350xi
Summary of Contents for Extron electronics ADA 2/GLI 350xi
- Page 1 © 2007 Extron Electronics. All rights reserved. User’s Manual Extron Electronics, Japan Kyodo Building, 16 Ichibancho Chiyoda-ku, Tokyo 102-0082 Japan +81.3.3511.7655 FAX +81.3.3511.7656 GLI 350xi and ADA 2/GLI 350xi Ground Loop Isolator and RGBHV Distribution Amplifier with Ground Loop Isolator 68-1445-01 Rev. B 11 07...
- Page 2 Safety Instructions • English Warning Power sources • This equipment should be operated only from the power source This symbol is intended to alert the user of important indicated on the product. This equipment is intended to be used with a main power operating and maintenance (servicing) instructions in system with a grounded (neutral) conductor.
-
Page 3: Fcc Class A Notice
安全须知 • 中文 这个符号提示用户该设备用户手册中 有重要的操作和维护说明。 这个符号警告用户该设备机壳内有暴 露的危险电压，有触电危险。 注意 阅读说明书 • 用 户 使 用 该 设 备 前 必 须 阅 读 并 理 解 所 有 安 全 和 使 用 说 明 。 保存说明书 • 用户应保存安全说明书以备将来使 用。 遵守警告 • 用户应遵守产品和用户指南上的所有安 全和操作说明。... -
Page 4: Table Of Contents
Appendix A • Specifications, Part Numbers, and Accessories ...A-1 Specifications ...A-2 Included Parts ...A-5 Optional Accessories ...A-5 All trademarks mentioned in this manual are the properties of their respective owners. GLI 350xi & ADA 2/GLI 350xi • Table of Contents ... 1-2 ..2-3 ... 3-2 ..3-3 68-1445-01.Rev. B 11.07 TOC-i... -
Page 5: Chapter One • Introduction
Table of Contents, cont’d GLI 350xi & ADA 2/GLI 350xi Chapter One Introduction About.the.GLI.350xi.and.ADA.2/GLI.350xi Features TOC-ii GLI 350xi & ADA 2/GLI 350xi • Table of Contents... -
Page 6: Chapter Two • Installation
Both models are rack and furniture mountable. The GLI 350xi is a one-input, one-output model; the ADA 2/GLI 350xi is a one-input, two-output unit. The terms "GLI" and "ground loop isolator" are used interchangeably in this manual to refer to either model. -
Page 7: Application Example
Projector Rear Mounting the GLI 350xi and ADA 2/GLI 350xi The GLI 350xi and ADA 2/GLI 350xi ground loop isolators can be set on a table, mounted on a rack shelf, or mounted under a desk or other furniture. Install the GLI near the display device(s) rather than near the source device. See the previous application example... -
Page 8: Rack Mounting
R IE IS OL Use 2 mounting holes on opposite corners. Rack mounting of the GLI in a 9.5" deep rack shelf GLI 350xi & ADA 2/GLI 350xi • Installation 1/4 Rack Width Front False Faceplate (2) 4-40 x 3/16" Screws 6"... -
Page 9: Under-Furniture Mounting
Installation, cont’d Under-furniture mounting The GLI 350xi or ADA 2/GLI 350xi can be mounted under furniture, such as a desk or table, using the optional MBU 125 mounting kit (Extron part #70-077-01), as follows. If rubber feet were previously installed on the bottom of the unit, remove them. -
Page 10: Front Panel Features And Operation
H/HV H/HV RGBHV RGBS H/HV H/HV (R-Y) (B-Y) Component Composite GLI 350xi & ADA 2/GLI 350xi • Operation GLI 350xi SERIES H/HV RGsB or RsGsBs H/HV S-video Rear Panel Features and Operation POWER 0.5A MAX GLI 350xi Rear Panel POWER 0.5A MAX... -
Page 11: Specifications, Part Numbers
Operation, cont’d Video output 2 (ADA 2/GLI 350xi only) — These BNC connectors accept RGBHV, RGBS, RGsB, RsGsBs, component video, composite video, and S-video inputs. Connect coaxial cables to the outputs, as shown in the previous illustration. GLI 350xi & ADA 2/GLI 350xi • Operation GLI 350xi &... -
Page 12: Appendix A • Specifications, Part Numbers, And Accessories
Impedance ... 75 ohms Return loss ... <-45 dB @ 5 MHz DC offset ... ±10 mV GLI 350xi & ADA 2/GLI 350xi • Specifications, Parts, Accessories Sync Input type ... RGBHV, RGBS, RGsB, RsGsBs Output type ... RGBHV, RGBS, RGsB, RsGsBs (follows... -
Page 13: Included Parts
Compliances ... CE, FCC Class A, VCCI, AS/NZS, ICES MTBF ... 30,000 hours Warranty ... 3 years parts and labor All nominal levels are at ±10%. Specifications are subject to change without notice. GLI 350xi & ADA 2/GLI 350xi • Specifications, Parts, Accessories Included Parts (7.52-112707-D4) Optional Accessories GLI 350xi & ADA 2/GLI 350xi • Specifications, Parts, Accessories These items are included in each order of the GLI 350xi or ADA 2/GLI 350xi. - Page 14 Specifications, Part Numbers, Accessories, cont’d GLI 350xi & ADA 2/GLI 350xi • Specifications, Parts, Accessories GLI 350xi & ADA 2/GLI 350xi • Specifications, Parts, Accessories...
- Page 15 Specifications, Part Numbers, Accessories, cont’d GLI 350xi & ADA 2/GLI 350xi • Specifications, Parts, Accessories...
