Command Function
Information Requests (continued)
Request part number
Show input connections status
Show temperature
Show transceiver module status
Show DA configuration switch position
FOX Extenders Control Program
The Extron FOX Extenders Control Program, which communicates with the FOX DA8 Plus via
the rear panel RS-232 port or front panel Configuration port of the unit, provides an easy
way to control the DA mute function and set reclocker rates for the inputs.
The program is compatible with Windows
operating systems. Updates to this program can be downloaded from the Extron website
(www.extron.com).

Installing the Software

The program is contained on the Extron Software Products DVD. Install the software as
follows:
1.
2.
3.
4.
ASCII Command
(Host to Unit)
N
0LS
20S
0*1I
E }
STAT
Insert the DVD into the drive. The Extron software DVD window should open
automatically (see figure 6). If it does not self-open, run
Figure 6.
Software DVD Window
Click the tab (see
Software
Scroll to the desired program and click
Figure 7. Software Installation
Follow the on-screen instructions. By default, the Windows installation creates a
C:\Program Files\Extron\FOX_Extenders directory, and it places the following four icons
into a group folder named Extron Electronics\FOX Extenders:
Check for FOX Extenders updates
•
FOX Extenders Control Program
•
FOX Extenders Help
•
Uninstall FOX Extenders Control Program
•
Response Additional description
(Unit to Host)
]
60-1171-nn nn indicates the transmission mode.
01 = multimode, 02 = singlemode.
X& X& X& X& X& ]
... Show light status of all inputs.
1 2 3 4 8
X*] X*
X( X( X( X( X( ]
Show all installed transceiver modules.
1 2 3 4 ... 8
X1)]
2000, Windows XP, Windows 7, and newer
®
figure 6).
figure
Install (see
FOX DA8 Plus • Remote Control
= degrees Fahrenheit.
from the DVD.
Launch.exe
7).
12
