Extron electronics FOX DA8 Plus User Manual page 26

Control/remote
Serial control port ........................... 1 RS-232, 3.5 mm captive screw connector, 3 pole (rear panel)
Baud rate and protocol ................... 9600 baud, 8 data bits, 1 stop bit, no parity
Serial control pin configurations ..... 1 = Tx, 2 = Rx, 3 = GND
USB control port ............................. 1 front panel female mini USB B
USB standards ................................ USB 2.0, low speed
Program control ............................. Extron control/configuration program for Windows
General
Power ............................................ 100 VAC to 240 VAC, 50-60 Hz, 20 watts, internal
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Cooling .......................................... Convection, vents on top and sides
Mounting
Rack mount ............................. Yes, with optional 1U rack shelf
Furniture mount ...................... Yes, with optional under-desk mounting kit or through-desk mounting kit
Enclosure type ................................ Metal
Enclosure dimensions ..................... 1.7" H x 8.7" W x 9.5" D (1U high, half rack wide)
Product weight ............................... 2.3 lbs (1 kg)
Shipping weight ............................. 4 lbs (2 kg)
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, c-UL, UL
EMI/EMC ................................. CE, C-tick, FCC Class A, FDA Class 1, ICES, VCCI,
MTBF ............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
:
NOTES • All nominal levels are at ±10%.
Specifications are subject to change without notice.
•
Extron Simple Instruction Set (SIS
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
(4.3 cm H x 22.1 cm W x 24.1 cm D)
(Depth excludes connectors.)
®
™ )
FOX DA8 Plus • Reference Information 20
