Table Of Contents - Extron electronics FOX DA8 Plus User Manual

Contents
Introduction ............................................
About this Guide ............................................. 1
About the FOX DA8 Plus .................................. 2
Features ........................................................... 3
Installation and Operation .....................
Rear Panel Features .......................................... 4
Front Panel Features ......................................... 7
System Operation ............................................ 8
Configuration .............................................. 8
Remote Control .......................................
Remote Control Ports ....................................... 9
Simple Instruction Set
™
Host-to-interface Communications ............. 10
Start-up Message ....................................... 10
Error Responses.......................................... 10
Timeout ..................................................... 10
Using the Command and Response Table ... 10
FOX Extenders Program ................................. 12
Installing the Software ............................... 12
Using the Program ..................................... 13
Firmware Upgrade ..................................... 15
1
4
9
Control ...................... 10
Reference Information ..........................
Specifications ................................................. 19
Part Numbers and Accessories ........................ 21
FOX DA8 Part Numbers .............................. 21
Included Parts ............................................ 21
Optional Accessories .................................. 21
Compatible Equipment .............................. 21
Fiber Cables ............................................... 22
Mounting the Unit ......................................... 23
Rack mounting UL Guidelines .................... 23
FOX DA8 Plus • Contents
19
v
