Tear-Off with Quick-Load (Straight-through)
Important!
Save the label indicating the
sensitivity number attached to
the media roll. You will need
this number to set the media
sensitivity, see Appendix 2.
1
Remove any empty core from the media
supply roll post.
Intermec EasyCoder F2 – User's Guide
In addition to the media load procedure for tear-off (straight-
through) operation described earlier in this chapter, the
EasyCoder F2 can optionally be fi tted with a set of Quick-Load
guides that makes media load much easier and quicker, especially
if the printer has a short side door. See Chapter 11, "Adjust-
ments" for installation instructions.
The Quick-Load guides allow a media as narrow as 40 mm
(1.57 inches)
Quick-Load cannot be combined with peel-off (self-strip) opera-
tion.
2
post and adjust the edge guide so the roll
becomes fl ush with the center section.
Chapter 4
Fit a new roll of media on the supply
Media Load
23
