Connections

Power

Computer

Intermec EasyCoder F2 – User's Guide
1 Place the printer on a level surface, near an AC outlet. You
should be able to easily access the printer to load media and
to remove the printout.
2 Check that the printer is switched off (position 0).
3 Connect the power cord between the receptacle on the rear
plate and to the electrical outlet (>90 to <264 VAC).
The Easycoder F2 is fi tted with one 25-pin D-style subminiature
(DB25) female connector for the RS-232 serial interface port
(see Appendix 3). The printer is also prepared for one optional
interface board (auto-sensing).
• RS-232 Serial Interface
Use the serial interface with the Intermec InterDriver or Inter-
mec LabelShop. Before you can use the serial interface, you
may need to set up the communication parameters, such as
baud rate, parity, etc. as described in Chapter 6, "Setting Up
the Printer."
• Parallel Interface Board
Optional. Refer to Appendix 3 and the separate documen-
tation delivered with the boards for connection and setup
instructions.
• EasyLAN 100i Interface Board
Optional. Refer to Appendix 3 and the separate documen-
tation delivered with the boards for connection and setup
instructions.
Switch off both PC and printer before connecting them together.
Chapter 2 Installation
15
