Appendix 3 Interfaces
EasyLAN 100i Interface Board
80
The Intermec EasyLAN 100i Ethernet interface board provides
the printer with a 10BaseT Ethernet or 100BaseTX Fast Ethernet
network connection. You can communicate with the printer via
a LAN (Local Area Network) or provide the printer with its own
home page, so you can reach the printer using a Web browser.
EasyLAN 100i supports most major computer systems and envi-
ronments. You can assign passwords to restrict both login and
printer access. The internal EasyLAN 100i Web pages allow you
to continuously monitor printer status and to upgrade the fl ash
memory of the printer when new fi rmware becomes available.
EasyLAN 100i supports SNMP for remote monitoring.
When an EasyLAN 100i interface board is installed in the
printer, some extra menus will be added to the Setup Mode (see
Chapter 7, "Setup Mode").
Intermec EasyCoder F2 – User's Guide
RJ-45
socket
