GarrettCom Magnum 6K25e Installation And User Manual page 11

Magnum 6K25e Gigabit Fiber Switch
For Gigabit module configuration options
GBPM-COTX
and provides one GBIC open transceiver port for a user-selectable GBIC transceiver
module
GBIC-SXSC
port with mm SC fiber connector
GBIC-LXSC10 GBIC transceiver module for use in GBPM-xOTX, one 1000BASE-
LX/LH port with 1310nm sgl. mode SC(10km) fiber connector
GBIC-LXSC25 GBIC transceiver module for use in GBPM-xOTX, one 1000BASE-
LX/LH port with 1310nm sgl. mode SC(25km) fiber connector
GBIC-LXSC40 GBIC transceiver module for use in GBPM-xOTX, one 1000BASE-ZX
port with 1550nm, sgl. mode SC(40km) fiber connector
GBIC transceiver module for use in GBPM-COTX, one LX port with mm SC fiber
connector
GBIC-LXSC70 GBIC transceiver module for use in GBPM-xOTX, one 1000BASE-ZX
port with 1550nm, sgl. mode SC(70km) fiber connector
GBIC-TP
1000BASE-T port, RJ-45 connector
6KM-BLNK
Magnum 6K25e or 6K25eR chassis
CONSOLE CBL
modem " connection (sometimes called an Xmodem cable), used to connect a PC or a
character terminal to the Management port.
CONSOLE USB Console attachment cable, serial to USB, cable with one DB9 for the
managed Switch and a USB interface for the USB connector to a PC.
Configuration options: only one A, B or C module slot of 6K-Series switch with
48VDC power input may be configured with a PoE Modules
New P6KP8-RJ45 8 port PoE module for 6ks with 48vdc PS, w/eight PoE power source
10/100 auto-negotiating auto cross RJ-45 ports.
New P6KP8-45RJ "4+4" port PoE module for 6ks with 48vdc PS, w/four PoE power
source and four 10/100 auto-negotiating auto cross RJ-45 ports
New P6KP8-45MT "4+4" port PoE module for 6ks with 48vdc PS, w/four PoE power
source and four 100 Mb 2km mm FX MTRJ connectors
New P6KP8-45MLC "4+4" port PoE module for 6ks with 48vdc PS, w/four PoE power
source and four 100 Mb 2km mm FX LC connectors
New P6KP8-45SLC "4+4" port PoE module for 6ks with 48vdc PS, w/four PoE power
source and four 100 Mb 15km sm FX LC connectors
New P6KP8-45-2MT "6+2" port PoE module for 6ks with 48vdc PS, w/four PoE power
source and two normal RJ-45 10/100 ports +two100 Mb 2km mm FX MTRJ connectors
www GarrettCom com .
One slot Gigabit 6K module for 6K25e Switches, uses one 6K25e slot
GBIC transceiver module for use in GBPM-xOTX, one 1000BASE-SX
GBIC transceiver module for use in GBPM-xOTX, one 802.3ab
Blank cover for one 6K25e (A,B,or C) module slot opening in a
Industry standard serial cable, DB-9 connectors for RS-232 " null-
6K PoE Modules with 48VDC Pass-Through
.
Installation and User Guide (10/07)
5
