CDM-600 Satellite Modem
Front Panel Operation
INFO: REMOTE
REMOTE-CONTROL= LOCAL
INTERFACE = RS-232
This screen shows if the unit is in Local or Remote mode, provides the details of the
electrical interface type selected, the unit's address and the baud rate selected. Pressing
ENTER takes the user back to the previous menu.
INFO: ALARMS MASK
ALARMS MASKED: TX-AIS
This screen shows only the alarm(s) that are currently masked:
•
•
•
•
•
•
•
If an alarm is not masked, a blank is displayed in the relevant screen position.
INFO: MISC
MISCELLANEOUS:
This screen shows the following:
•
•
•
AGC
TX-AIS
RX-AIS
BUF-SLIP
AGC
EBNO
SAT
TERR
1:1 SWITCH = NOT CONNECTED
Test Mode
1:1 Link Status
Redundancy Status
ADDRESS= 0000
9600 BAUD N81
RX-AIS
EBNO
SAT
NORMAL
6–35
MN/CDM600.IOM
BUF-SLIP
ONLINE
Revision 7
