SRM Power-Up Display

Following the initial SCM power-up and the five test phases, the SRM
console takes control of the remaining portion of system power-up.
Example 6–2 SRM Power-Up Display
System Primary QBB0 : 0
System Primary CPU
Par hrd/sft CPU Mem
QBB# 3210 3210
(-) 0/30 ---P PP
(-) 1/31 -P-P PP
(-) 2/32 --P- --P-
(-) 3/33 ---P -P--
HSwitch Type Cables 7 6 5 4 3 2 1 0
HPM40 4-port
PCI Rise1-1 Rise1-0
Cab 7 6 5 4 3 2 1
10 - - - - - - -
11 - - - - - - -
OpenVMS PALcode V1.75-1, Tru64 UNIX PALcode V1.68-1
system = QBB 0 1 2 3
QBB 0 = CPU 0
QBB 1 = CPU 0 2
QBB 2 = CPU 1
QBB 3 = CPU 0
shared RAM version is 1.3
hose 24 has a standard I/O module
starting console on CPU 0
initialized idle PCB
initializing semaphores
initializing heap
initial heap 2c0c0
memory low limit = 1f2000
heap = 2c0c0, 1ffc0
initializing driver structures
initializing idle process PID
initializing file system
initializing timer data structures
lowering IPL
6-6 AlphaServer GS80/160/320 User's Guide
: 0 on QBB0
IOR3 IOR2 IOR1 IOR0
(pci_box.rio)
--.- --.- Px.x P1.0
--.- --.- --.- --.-
--.- --.- --.- --.-
--.- --.- Px.x P0.0
- - - - E E E E
Rise0-1 Rise0-0
7 6 5 4 3 2 1
- - - - - - S
- - L - L M S
+ HS
+ Mem 0 1 + Dir + IOP + PCA 0
+ Mem 0 1 + Dir + IOP + PCA
+ Mem 1 + Dir + IOP + PCA
+ Mem 2 + Dir + IOP + PCA 0
GP QBB Dir PS
Mod BP Mod 321 (:C)
P P P PPP
P P P PPP
P P P PP-
P P P PP-
Temp(:C)
29.0
RIO PS Temp
1 0 21 (:C)
- * P- 27.5
- * PP 27.0
+ GP
+ GP
+ GP
+ GP
Temp
26.5
29.0
25.0
27.0
(Hard QBB 0)
(Hard QBB 1)
(Hard QBB 2)
(Hard QBB 3)
