System Box

The system box contains two QBBs. Figure 3–5 shows a fully populated
QBB as seen from the front of the cabinet. Figure 3–6 shows the second
QBB at the rear of the cabinet.
Figure 3–5 System Box QBB (Cabinet Front)
Memory 2 Memory 0 I/O Riser
Directory CPU 3 CPU 1 I/O Riser Signal Cable
Clock CPU 2 CPU 0 PSM Auxiliary
Splitter Power
Main
Memory 3 Memory 1
Power
PK0610
