8.4

Console Device Setup

You can use the SCM from a console device connected to the system or
a modem hookup. As shown in Figure 8–4, local connection is made
from the local port
to the modem port
Figure 8–4 Setups for SCM (PCI Box)
Note: Both the local port and the modem port are set at:
1 start bit, 8 data bits, 1 stop bit, no parity.
Local port defaults: baud rate is 9600, flow control is soft.
Modem port defaults: baud rate is 57600, flow control is hard.
. You connect remotely from a modem connected
.
Using the System Control Manager
1
2
PK-0650-99
8-11
