The CPU, memory, power, and I/O riser modules plug into the backplane
located at the bottom of the system drawer. Callouts in Figure 4–3 point to the
location of the following system drawer modules:
–
CPU module
—
Memory module
˜
Directory module
™
Power modules
š
Power system manager (PSM) module
›
I/O riser modules
œ
Clock splitter module
Figure 4–4 System Drawer Backplane
2
1
4
3
2
1
1
2
5
7
6
GS80 Rack System Overview
1
2
PK-0632-99
4-7
