Connect Unit - Icom IC-M802 Service Manual

[DISPLAY UNIT]
REF ORDER
NO. NO.
DS8321 5040002600 LED
DS8322 5040002600 LED
DS8323 5040002600 LED
DS8340 5040002310 S.LED
DS8341 5040002310 S.LED
DS8342 5040002310 S.LED
DS8343 5040002310 S.LED
DS8344 5040002310 S.LED
DS8345 5040002310 S.LED
DS8346 5040002310 S.LED
DS8347 5040002310 S.LED
DS8348 5040002310 S.LED
DS8349 5040002310 S.LED
DS8350 5040002310 S.LED
W8201 7030000010 S.JUMPER
W8202 7030000010 S.JUMPER
W8238 7030003860 S.JUMPER
W8242 7030003860 S.JUMPER
W8270 7030003860 S.JUMPER
W8271 7030003860 S.JUMPER
W8280 7030003860 S.JUMPER
W8281 7030003860 S.JUMPER
W8296 7030003860 S.JUMPER
W8340 7030003860 S.JUMPER
EP8201 0910054714 PCB
EP8205 6910012350 S.BEAD
EP8292 6910012350 S.BEAD
EP8293 6910012350 S.BEAD
EP8294 6910012350 S.BEAD
EP8295 6910012350 S.BEAD
EP8296 6910012350 S.BEAD
[JACK UNIT]
REF ORDER
NO. NO.
J8601 6510022620 S.CONNECTOR 10FMN-BMTTR-A-TBT
J8602 6510023060 CONNECTOR
EP8601 0910054961 PCB
[SENSOR UNIT]
REF ORDER
NO. NO.
S8801 2250000220 ENCODER
S8802 2250000220 ENCODER
EP8801 0910054732 PCB
DESCRIPTION
TLYU1002
TLYU1002
TLYU1002
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
MCR10EZHJ JPW (000)
MCR10EZHJ JPW (000)
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
B 5727D
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
DESCRIPTION
TCS7186-01-201
B 5812A
DESCRIPTION
TP90N937E20-15F-1540
TP90N937E20-15F-1540
B 5729B
[VR UNIT]
REF ORDER
NO. NO.
R8901 7210002360 VARIABLE
EP8901 0910054742 PCB

[CONNECT UNIT]

REF ORDER
NO. NO.
IC8240 1140010010 S.IC
L8220 6200001830 S.COIL
L8221 6200001830 S.COIL
R8241 7030003830 S.RESISTOR
R8242 7030003840 S.RESISTOR
R8243 7030003640 S.RESISTOR
R8244 7030003640 S.RESISTOR
R8245 7030003640 S.RESISTOR
R8246 7030003830 S.RESISTOR
C8230 4030011600 S.CERAMIC
C8231 4030011600 S.CERAMIC
C8232 4550006450 S.TANTALUM
C8233 4550006450 S.TANTALUM
C8234 4550006450 S.TANTALUM
C8235 4550006450 S.TANTALUM
C8236 4550006450 S.TANTALUM
C8237 4030011600 S.CERAMIC
J8220 6510022540 S.CONNECTOR 20FMN-BMTTR-A-TBT
DS8220 5030002280 LCD
EP8220 0910054783 PCB
5 - 19
DESCRIPTION
TP96N97-15F-10KB-1301
B 5730B
DESCRIPTION
HD66421TBOL
NL 322522T-100J
NL 322522T-100J
ERJ3GEYJ 185 V (1.8 MΩ)
ERJ3GEYJ 225 V (2.2 MΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 185 V (1.8 MΩ)
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
ECST1EY105R
ECST1EY105R
ECST1EY105R
ECST1EY105R
ECST1EY105R
C1608 JB 1E 104K-T
HLC7700-018800
B 5751C
S.=Surface mount
