[FILTER UNIT]
REF ORDER
NO. NO.
C7105 4010006410 CERAMIC
C7106 4010005830 CERAMIC
C7108 4010005370 CERAMIC
C7121 4510005480 ELECTROLYTIC 50 MV 1 HC
C7122 4030006880 S.CERAMIC
C7124 4030012480 S.CERAMIC
C7125 4010005930 CERAMIC
C7126 4030011120 S.CERAMIC
C7127 4030012480 S.CERAMIC
C7128 4010005880 CERAMIC
C7129 4010005360 CERAMIC
C7130 4030011510 S.CERAMIC
C7131 4030011070 S.CERAMIC
C7132 4010005360 CERAMIC
C7133 4030006880 S.CERAMIC
C7136 4010005850 CERAMIC
C7137 4030011730 S.CERAMIC
C7151 4510005480 ELECTROLYTIC 50 MV 1 HC
C7152 4030006880 S.CERAMIC
C7153 4030014460 S.CERAMIC
C7154 4010005930 CERAMIC
C7155 4030012480 S.CERAMIC
C7156 4030011120 S.CERAMIC
C7157 4010005930 CERAMIC
C7158 4030014460 S.CERAMIC
C7160 4030006880 S.CERAMIC
C7163 4010005850 CERAMIC
C7181 4510005480 ELECTROLYTIC 50 MV 1 HC
C7182 4030006880 S.CERAMIC
C7183 4030012480 S.CERAMIC
C7184 4030012480 S.CERAMIC
C7185 4010005880 CERAMIC
C7186 4030011510 S.CERAMIC
C7187 4010005370 CERAMIC
C7188 4030011180 S.CERAMIC
C7190 4030006880 S.CERAMIC
C7193 4010005850 CERAMIC
C7211 4510005480 ELECTROLYTIC 50 MV 1 HC
C7212 4030006880 S.CERAMIC
C7214 4030011240 S.CERAMIC
C7216 4030011190 S.CERAMIC
C7217 4030012480 S.CERAMIC
C7218 4030006880 S.CERAMIC
C7221 4030014460 S.CERAMIC
C7222 4010005860 CERAMIC
C7223 4030014460 S.CERAMIC
C7224 4030011210 S.CERAMIC
C7225 4030011120 S.CERAMIC
C7241 4030006880 S.CERAMIC
C7242 4030011730 S.CERAMIC
C7243 4030011510 S.CERAMIC
C7244 4030011180 S.CERAMIC
C7245 4030011070 S.CERAMIC
C7247 4030011180 S.CERAMIC
C7248 4030011210 S.CERAMIC
C7249 4030011230 S.CERAMIC
C7250 4030006880 S.CERAMIC
C7253 4010005830 CERAMIC
C7254 4030011180 S.CERAMIC
C7272 4030006870 S.CERAMIC
C7274 4030006870 S.CERAMIC
C7275 4610002230 TRIMMER
C7277 4010005850 CERAMIC
C7278 4030007090 S.CERAMIC
C7279 4030007090 S.CERAMIC
C7301 4030006880 S.CERAMIC
C7302 4030006880 S.CERAMIC
C7303 4030006880 S.CERAMIC
C7304 4030006880 S.CERAMIC
C7321 4030011730 S.CERAMIC
C7322 4030011170 S.CERAMIC
C7323 4030011730 S.CERAMIC
C7325 4030011790 S.CERAMIC
C7332 4030006880 S.CERAMIC
C7345 4030006880 S.CERAMIC
RL7031 6330001570 RELAY
RL7032 6330001570 RELAY
RL7061 6330001570 RELAY
RL7062 6330001570 RELAY
RL7091 6330001570 RELAY
DESCRIPTION
HM13SJ SL 471J 500V
HM74SJ SL 151J 500V
HM11SJ SL 331J 500V
C1608 JB 1H 472K-T
GRM31M2C2H121JV01L (GRM42-6 CH)
HM11SJ SL 391J 500V
GRM31M2C2H100JV01L (GRM42-6 CH)
GRM31M2C2H121JV01L (GRM42-6 CH)
HM95SJ SL 271J 500V
HM11SJ SL 301J 500V
GRM31M2C2H560JV01L (GRM42-6 CH)
GRM31M2C2H5R0CY21L (GRM42-6 CH)
HM11SJ SL 301J 500V
C1608 JB 1H 472K-T
HM95SJ SL 181J 500V
GRM31M2C2H101JV01L (GRM42-6 CH)
C1608 JB 1H 472K-T
GRM31M2C2H820JV01L (GRM42-6 CH)
HM11SJ SL 391J 500V
GRM31M2C2H121JV01L (GRM42-6 CH)
GRM31M2C2H100JV01L (GRM42-6 CH)
HM11SJ SL 391J 500V
GRM31M2C2H820JV01L (GRM42-6 CH)
C1608 JB 1H 472K-T
HM95SJ SL 181J 500V
C1608 JB 1H 472K-T
GRM31M2C2H121JV01L (GRM42-6 CH)
GRM31M2C2H121JV01L (GRM42-6 CH)
HM95SJ SL 271J 500V
GRM31M2C2H560JV01L (GRM42-6 CH)
HM11SJ SL 331J 500V
GRM31M2C2H220JV01L (GRM42-6 CH)
C1608 JB 1H 472K-T
HM95SJ SL 181J 500V
C1608 JB 1H 472K-T
GRM31M2C2H470JV01L (GRM42-6 CH)
GRM31M2C2H270JV01L (GRM42-6 CH)
GRM31M2C2H121JV01L (GRM42-6 CH)
C1608 JB 1H 472K-T
GRM31M2C2H820JV01L (GRM42-6 CH)
HM95SJ SL 201J 500V
GRM31M2C2H820JV01L (GRM42-6 CH)
GRM31M2C2H330JV01L (GRM42-6 CH)
GRM31M2C2H100JV01L (GRM42-6 CH)
C1608 JB 1H 472K-T
GRM31M2C2H101JV01L (GRM42-6 CH)
GRM31M2C2H560JV01L (GRM42-6 CH)
GRM31M2C2H220JV01L (GRM42-6 CH)
GRM31M2C2H5R0CY21L (GRM42-6 CH)
GRM31M2C2H220JV01L (GRM42-6 CH)
GRM31M2C2H330JV01L (GRM42-6 CH)
GRM31M2C2H390JV01L (GRM42-6 CH)
C1608 JB 1H 472K-T
HM74SJ SL 151J 500V
GRM31M2C2H220JV01L (GRM42-6 CH)
C1608 JB 1H 222K-T
C1608 JB 1H 222K-T
TZB4Z100DB10B00 (TZBX4Z100BD110)
HM95SJ SL 181J 500V
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
GRM31M2C2H101JV01L (GRM42-6 CH)
GRM31M2C2H180JV01L (GRM42-6 CH)
GRM31M2C2H101JV01L (GRM42-6 CH)
GRM55RF52A684ZD01L (GRM44-1 Y5V)
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
AJS1315
AJS1315
AJS1315
AJS1315
AJS1315
[FILTER UNIT]
REF ORDER
NO. NO.
RL7092 6330001570 RELAY
RL7121 6330001570 RELAY
RL7122 6330001570 RELAY
RL7151 6330001570 RELAY
RL7152 6330001570 RELAY
RL7181 6330001570 RELAY
RL7182 6330001570 RELAY
RL7211 6330001570 RELAY
RL7212 6330001570 RELAY
RL7241 6330001570 RELAY
RL7242 6330001570 RELAY
RL7301 6330000780 RELAY
CP7331 6910009670 S.CHECK P
CP7332 6910009670 S.CHECK P
J7001 6510007900 CONNECTOR
J7311 6510007020 CONNECTOR
J7321 6510007900 CONNECTOR
J7331 6510022560 CONNECTOR
P7001 6510003240 CONNECTOR
P7321 6510003240 CONNECTOR
W7001 9014130400 WIRE
W7002 9086700300 WIRE
W7321 9012961790 WIRE
W7322 9086700300 WIRE
W7333 7030003860 S.JUMPER
W7334 7030003860 S.JUMPER
W7335 7030003860 S.JUMPER
W7336 7030003860 S.JUMPER
W7337 7030003860 S.JUMPER
W7338 7030003860 S.JUMPER
W7339 7030003860 S.JUMPER
W7340 7030003860 S.JUMPER
WS1 8970024020 CABLE
EP7001 0910054704 PCB

[DRIVER UNIT]

REF ORDER
NO. NO.
Q6851 1590003060 S.FET
R6851 7030010520 S.RESISTOR
R6852 7030000020 S.RESISTOR
C6851 4030004750 S.CERAMIC
EP6851 0910054751 PCB
5 - 14
DESCRIPTION
AJS1315
AJS1315
AJS1315
AJS1315
AJS1315
AJS1315
AJS1315
AJS1315
AJS1315
AJS1315
AJS1315
AGP 2013 (DSP1-DC12V)
HK3-S-T
HK3-S-T
TBP-P01X-A1 (B1)
TMP-J01X-V6
TBP-P01X-A1 (B1)
16FMN-BTRK-A
TMP-P01X-A1
TMP-P01X-A1
62/99/150/C24/C31
08
62/99/280/C31/C24
08
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
SX2429 1.5D COAXIAL TUBE (2)/FI
B 5725D
DESCRIPTION
PD55015S
ERJ1TYJ 101U (100 Ω)
MCR10EZHJ 1 Ω (010)
C2012 JB 1H 103K-T
B 5744A
S.=Surface mount
