Icom IC-M802 Service Manual page 42

[VARISTOR-1 BOARD]
REF ORDER
NO. NO.
D6431 1790001760 S.VARISTOR
C6431 4030008920 S.CERAMIC
EP6431 0910054761 PCB
[VARISTOR-2 BOARD]
REF ORDER
NO. NO.
D6432 1790001760 S.VARISTOR
C6432 4030008920 S.CERAMIC
EP6432 0910054771 PCB
DESCRIPTION
MA30-(TX)
C1608 JB 1H 473K-T
B 5746A
DESCRIPTION
MA30-(TX)
C1608 JB 1H 473K-T
B 5747A
EX-2432
[DSP UNIT]
REF ORDER
NO. NO.
IC1 1130010010 S.IC
IC3 1130010540 S.IC
IC4 1130010540 S.IC
IC51 1130010010 S.IC
IC101 1130010520 S.IC
IC102 1110004770 S.IC
IC152 1180002320 S.REG
IC161 1180002020 S.REG
IC171 1180002270 S.REG
IC201 1130010680 S.IC
IC202 1130008040 S.IC
IC203 1130008810 S.IC
IC301 1140010330 S.IC
IC401 1130010550 S.IC
IC403 1130010530 S.IC
IC404 1130010530 S.IC
IC405 1130004670 S.IC
IC406 1130010540 S.IC
IC501 1190001610 S.IC
IC601 1110005420 S.IC
IC651 1110005420 S.IC
IC701 1110001900 S.IC
IC801 1130010560 S.IC
Q201 1590001660 S.TRANSISTOR XP4312 (TX)
Q301 1590000430 S.TRANSISTOR DTC144EUA T106
Q302 1590000430 S.TRANSISTOR DTC144EUA T106
D301 1750000370 S.DIODE
D302 1750000370 S.DIODE
D303 1750000370 S.DIODE
D304 1750000370 S.DIODE
D901 1790000970 S.DIODE
X1 6050009860 S.XTAL
X51 6050011270 S.XTAL
L1 6200003280 S.COIL
L2 6200003280 S.COIL
L3 6200003280 S.COIL
L51 6200003280 S.COIL
L52 6200001980 S.COIL
L101 6200003280 S.COIL
L102 6200003280 S.COIL
L301 6200003280 S.COIL
L302 6200009840 S.COIL
L401 6200003280 S.COIL
L403 6200003280 S.COIL
L404 6200003280 S.COIL
L405 6200003280 S.COIL
L406 6200003280 S.COIL
L501 6200003280 S.COIL
L502 6200003280 S.COIL
L601 6200002040 S.COIL
L651 6200002040 S.COIL
L701 6200002040 S.COIL
L801 6200003280 S.COIL
R1 7030003800 S.RESISTOR
R2 7030003440 S.RESISTOR
R3 7030003640 S.RESISTOR
R51 7030003800 S.RESISTOR
R52 7030003320 S.RESISTOR
R151 7030007240 S.RESISTOR
R161 7030008190 S.RESISTOR
R162 7030007510 S.RESISTOR
R171 7030007180 S.RESISTOR
R201 7030003640 S.RESISTOR
R303 7030003480 S.RESISTOR
R304 7030003480 S.RESISTOR
R305 7030003560 S.RESISTOR
R306 7030003560 S.RESISTOR
R307 7030003560 S.RESISTOR
R308 7030003560 S.RESISTOR
R309 7030003560 S.RESISTOR
5 - 15
DESCRIPTION
TC7WHU04FU
SN74AHC74PWR
SN74AHC74PWR
TC7WHU04FU
SN74HCT244APWR
BU9480F-E2
TK11218CMCL
BA033FP-E2
TK11250CMCL
M29W102BB-70N1
TC7SH04FU
TC7SH32FU (TE85L)
TMS320VC33PGEA120
SN74AHC595PWR
SN74AHCT374PWR
SN74AHCT374PWR
BU4021BF-T1
SN74AHC74PWR
AK4528-VF
BA15532F-E2
BA15532F-E2
µPC4570G2-T1
SN74AHC244PWR
DA221 TL
DA221 TL
DA221 TL
DA221 TL
MA729 (TX)
CR-566 (12.288 MHz)
CR-709 (60.000 MHz)
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-1R0J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
LQH 3C 2R2M 34
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-2R2J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-2R2J
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ12YJ680U (68 Ω)
ERJ12YJ330U (33 Ω)
ERJ12YJ270U (27 Ω)
ERJ12YJ150U (15 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
S.=Surface mount
