Ant Unit; Connect Unit - Icom IC-F24 Service Manual

[MAIN UNIT]
REF ORDER
NO. NO.
C324 4030017420 S.CER ECJ0EC1H470J
C325 4550006250 S.TAN TEESVA 1A 106M8L
C326 4510006940 S.ELE EEVFC0J101P
C333 4030017420 S.CER ECJ0EC1H470J
C335 4030018860 S.CER ECJ0EB0J105K
C339 4030016930 S.CER ECJ0EB1A104K
C340 4030016930 S.CER ECJ0EB1A104K
C341 4030016930 S.CER ECJ0EB1A104K
C342 4030017630 S.CER ECJ0EC1H120J
C343 4030017580 S.CER ECJ0EC1H060C
C344 4030017640 S.CER ECJ0EC1H150J
C345 4030016930 S.CER ECJ0EB1A104K
C346 4030016930 S.CER ECJ0EB1A104K
C347 4030016790 S.CER ECJ0EB1C103K
C348 4030016930 S.CER ECJ0EB1A104K
C349 4030016930 S.CER ECJ0EB1A104K
C350 4030017460 S.CER ECJ0EB1E102K
C354 4030017460 S.CER ECJ0EB1E102K
C355 4030018080 S.CER ECJ0EB1H182K
C356 4030018910 S.CER C1608 JB 0J 475K-T
C357 4030017400 S.CER ECJ0EC1H220J
J1 6510021900 S.CNR BM02B-ASRS-TF
J2 6450001680 CNR HSJ1122-010010
J3 6450002250 CNR HSJ1456-010320
J4 6510018430 S.CNR AXN330C038P
J5 6510021900 S.CNR BM02B-ASRS-TF
[US2S], [US3S], [EU2S], [GE2S], [GE3S] only
F1 5210000830 S.FUS ERBFE3R00U
DS1 5040002670 S.LED CL-165HR/YG
MC1 7700002540 MIC SKP-4538
S1 2260002840 SW SKHLLFA010
S2 2260002800 S.SW SW-167 (SKQTLAE010)
S3 2260002800 S.SW SW-167 (SKQTLAE010)
S4 2250000490 ECR TP70TF5163-15.9F-2775
[US2], [US3], [EU2], [GE2], [GE3] only
EP1 6910015370 S.BEA ACZ1005Y-102-T
EP2 0910057942 PCB B 6161B
EP3 6910015370 S.BEA ACZ1005Y-102-T
[CHASSIS UNIT]
REF ORDER
NO. NO.
J1 6910015910 CNR ANT CONNECTOR-104
J2 6910015860 CNR IMSA-6277S-02A-G
S1 2260002870 SW AS-243-A13
[US2S], [US3S], [EU2S], [GE2S], [GE3S] only
SP1 2510001060 SP K036NA500-47
W1 8900009640 CBL OPC-963
W2 8900009640 CBL OPC-963
[US2S], [US3S], [EU2S], [GE2S], [GE3S] only

[ANT UNIT]

REF ORDER
NO. NO.
L601 6200008240 S.COL 0.30-0.9-5TL 14N
C601 4030017600 S.CER ECJ0EC1H080C
EP601 0910057920 PCB B 6210

[CONNECT UNIT]

REF ORDER
NO. NO.
C501 4030017460 S.CER ECJ0EB1E102K
C502 4030016930 S.CER ECJ0EB1A104K
J501 6910016390 CNR IMSA-9230B-1-02Z145-PT1
EP501 0910057930 PCB B 6160
DESCRIPTION M.
T
T
B
B
B
B
B
B
B
B
B
B
B
T
T
T
T
T
T
T
T
T
B
T
T
T
B
B
T
T
DESCRIPTION M.
DESCRIPTION M.
B
B
DESCRIPTION M.
T
T
S.=Surface mount
H/V
LOCATION
85/13.7
90.6/17.2
87.8/8.9
76.8/39.9
57.2/21.1
5.9/17.2
9.3/12.5
5.9/10.1
18.3/4.2
5.6/4.2
7.6/9.1
11/11.2
11/10.1
8.8/6.5
6/10
21.3/14.9
59.4/43.4
14.2/24.4
42.9/22.7
35.3/20.6
79/25.5
86.6/6.8
11.8/30.6
50.4/11.7
98/14.5
102.8/12.4
99.4/44.2
60.9/44.2
57/29.9
34.7/32
H/V
LOCATION
H/V
LOCATION
7.2/12.5
5.8/15.3
H/V
LOCATION
18.3/15.3
9.3/15.3
6 - 5
