Icom IC-M802 Service Manual page 33

[MAIN UNIT]
REF ORDER
NO. NO.
C160 4030007170 S.CERAMIC
C161 4030011600 S.CERAMIC
C162 4030007160 S.CERAMIC
C163 4030011600 S.CERAMIC
C164 4030007150 S.CERAMIC
C165 4030011600 S.CERAMIC
C166 4030007130 S.CERAMIC
C167 4030011600 S.CERAMIC
C168 4030011600 S.CERAMIC
C169 4030006860 S.CERAMIC
C170 4030011600 S.CERAMIC
C171 4030006850 S.CERAMIC
C172 4030011600 S.CERAMIC
C173 4030010760 S.CERAMIC
C174 4030011600 S.CERAMIC
C175 4030007040 S.CERAMIC
C201 4030011600 S.CERAMIC
C202 4030007120 S.CERAMIC
C203 4030007050 S.CERAMIC
C204 4030007150 S.CERAMIC
C205 4030006990 S.CERAMIC
C206 4030007130 S.CERAMIC
C207 4030011600 S.CERAMIC
C208 4030006880 S.CERAMIC
C209 4030011600 S.CERAMIC
C210 4030011600 S.CERAMIC
C211 4030006880 S.CERAMIC
C212 4030011600 S.CERAMIC
C213 4030007000 S.CERAMIC
C214 4030006860 S.CERAMIC
C215 4030006990 S.CERAMIC
C217 4030006860 S.CERAMIC
C218 4030006880 S.CERAMIC
C219 4030006880 S.CERAMIC
C220 4030006880 S.CERAMIC
C221 4030006880 S.CERAMIC
C223 4030006880 S.CERAMIC
C224 4030006880 S.CERAMIC
C301 4030006880 S.CERAMIC
C302 4030006970 S.CERAMIC
C303 4030006960 S.CERAMIC
C305 4030006850 S.CERAMIC
C307 4030011280 S.CERAMIC
C308 4030009580 S.CERAMIC
C309 4030011600 S.CERAMIC
C310 4030006880 S.CERAMIC
C311 4030010770 S.CERAMIC
C312 4030011600 S.CERAMIC
C314 4030006860 S.CERAMIC
C401 4030011600 S.CERAMIC
C402 4030006880 S.CERAMIC
C403 4030011600 S.CERAMIC
C404 4030011600 S.CERAMIC
C405 4030006880 S.CERAMIC
C406 4030011600 S.CERAMIC
C407 4030006880 S.CERAMIC
C408 4030011600 S.CERAMIC
C409 4030011600 S.CERAMIC
C410 4030011600 S.CERAMIC
C411 4030011600 S.CERAMIC
C412 4030006880 S.CERAMIC
C413 4030007140 S.CERAMIC
C414 4030007160 S.CERAMIC
C501 4030011600 S.CERAMIC
C502 4030006880 S.CERAMIC
C503 4030011600 S.CERAMIC
C504 4030006880 S.CERAMIC
C505 4030006880 S.CERAMIC
C506 4030011600 S.CERAMIC
C507 4030011600 S.CERAMIC
C508 4030011600 S.CERAMIC
C509 4030011600 S.CERAMIC
C510 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C511 4030011600 S.CERAMIC
C516 4030011600 S.CERAMIC
C517 4030011600 S.CERAMIC
C518 4030011600 S.CERAMIC
C519 4030011600 S.CERAMIC
C520 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C521 4030011600 S.CERAMIC
C601 4030006880 S.CERAMIC
C602 4030006880 S.CERAMIC
DESCRIPTION
C1608 CH 1H 221J-T
C1608 JB 1E 104K-T
C1608 CH 1H 181J-T
C1608 JB 1E 104K-T
C1608 CH 1H 151J-T
C1608 JB 1E 104K-T
C1608 CH 1H 101J-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
C1608 JB 1H 471K-T
C1608 JB 1E 104K-T
C1608 CH 1H 331J-T
C1608 JB 1E 104K-T
C1608 CH 1H 180J-T
C1608 JB 1E 104K-T
C1608 CH 1H 820J-T
C1608 CH 1H 220J-T
C1608 CH 1H 151J-T
C1608 CH 1H 080D-T
C1608 CH 1H 101J-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 CH 1H 090D-T
C1608 JB 1H 102K-T
C1608 CH 1H 080D-T
C1608 JB 1H 102K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 CH 1H 060D-T
C1608 CH 1H 050C-T
C1608 JB 1H 471K-T
C1608 CH 1H 271J-T
C1608 JB 1H 681K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1H 392K-T
C1608 JB 1E 104K-T
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 CH 1H 121J-T
C1608 CH 1H 181J-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
[MAIN UNIT]
REF ORDER
NO. NO.
C603 4030006880 S.CERAMIC
C604 4030006860 S.CERAMIC
C605 4030010760 S.CERAMIC
C606 4030007010 S.CERAMIC
C607 4030009510 S.CERAMIC
C608 4030007010 S.CERAMIC
C609 4030006970 S.CERAMIC
C610 4030009510 S.CERAMIC
C611 4030011600 S.CERAMIC
C612 4030007060 S.CERAMIC
C701 4030011600 S.CERAMIC
C702 4030011600 S.CERAMIC
C703 4030011600 S.CERAMIC
C705 4030011600 S.CERAMIC
C706 4030007070 S.CERAMIC
C707 4030006970 S.CERAMIC
C709 4030007080 S.CERAMIC
C710 4030007040 S.CERAMIC
C711 4030007050 S.CERAMIC
C712 4030011600 S.CERAMIC
C714 4030011600 S.CERAMIC
C715 4030006960 S.CERAMIC
C716 4030006860 S.CERAMIC
C717 4030006860 S.CERAMIC
C718 4030006860 S.CERAMIC
C720 4030007080 S.CERAMIC
C801 4030011600 S.CERAMIC
C802 4030011600 S.CERAMIC
C804 4030006880 S.CERAMIC
C805 4030006880 S.CERAMIC
C806 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C901 4030011600 S.CERAMIC
C902 4030011600 S.CERAMIC
C903 4030006880 S.CERAMIC
C904 4030011600 S.CERAMIC
C905 4030011600 S.CERAMIC
C906 4030011600 S.CERAMIC
C907 4030011600 S.CERAMIC
C908 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C909 4030011600 S.CERAMIC
C910 4030011600 S.CERAMIC
C1001 4030011600 S.CERAMIC
C1002 4030011600 S.CERAMIC
C1003 4030011600 S.CERAMIC
C1004 4030009970 S.CERAMIC
C1005 4030010040 S.CERAMIC
C1006 4030006880 S.CERAMIC
C1007 4030006880 S.CERAMIC
C1008 4030006880 S.CERAMIC
C1010 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1011 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1012 4030011600 S.CERAMIC
C1051 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1052 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1054 4030006900 S.CERAMIC
C1055 4030006860 S.CERAMIC
C1056 4030008880 S.CERAMIC
C1057 4030008880 S.CERAMIC
C1058 4030008880 S.CERAMIC
C1059 4030006900 S.CERAMIC
C1061 4030006860 S.CERAMIC
C1062 4030008880 S.CERAMIC
C1063 4030008880 S.CERAMIC
C1064 4030008880 S.CERAMIC
C1101 4030011600 S.CERAMIC
C1102 4030011600 S.CERAMIC
C1201 4030006880 S.CERAMIC
C1202 4030011600 S.CERAMIC
C1203 4030011600 S.CERAMIC
C1204 4030008680 S.CERAMIC
C1205 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C1206 4030006860 S.CERAMIC
C1207 4030008680 S.CERAMIC
C1208 4030008680 S.CERAMIC
C1209 4030011600 S.CERAMIC
C1210 4030008680 S.CERAMIC
C1211 4030008680 S.CERAMIC
C1212 4030008680 S.CERAMIC
C1213 4030008680 S.CERAMIC
C1214 4030011600 S.CERAMIC
C1301 4030011600 S.CERAMIC
C1302 4030011600 S.CERAMIC
5 - 6
DESCRIPTION
C1608 JB 1H 472K-T
C1608 JB 1H 102K-T
C1608 CH 1H 331J-T
C1608 CH 1H 100D-T
C1608 CH 1H 010B-T
C1608 CH 1H 100D-T
C1608 CH 1H 060D-T
C1608 CH 1H 010B-T
C1608 JB 1E 104K-T
C1608 CH 1H 270J-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 CH 1H 330J-T
C1608 CH 1H 060D-T
C1608 CH 1H 390J-T
C1608 CH 1H 180J-T
C1608 CH 1H 220J-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 CH 1H 050C-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 390J-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 182K-T
C1608 JB 1H 561K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
C1608 JB 1H 223K-T
C1608 JB 1H 223K-T
C1608 JB 1H 223K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
C1608 JB 1H 223K-T
C1608 JB 1H 223K-T
C1608 JB 1H 223K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C2012 JF 1C 105Z-T
C1608 JB 1H 102K-T
C2012 JF 1C 105Z-T
C2012 JF 1C 105Z-T
C1608 JB 1E 104K-T
C2012 JF 1C 105Z-T
C2012 JF 1C 105Z-T
C2012 JF 1C 105Z-T
C2012 JF 1C 105Z-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
S.=Surface mount
