SECTION 1
• IC-M802
' ' GENERAL
• Frequency coverage
• Mode
• Antenna impedance
• Frequency stability
• Power supply requirement
• Current drain (at 13.6 V DC)
• Usable temperature range
• Dimensions (projections not included)
• Weight
' ' TRANSMITTER
• Output power
• Spurious emissions
• Carrier suppressions
• Unwanted sideband suppresion
• Microphone impedance
' ' RECEIVER
• Sensitivity
(Receiver)
(DSC)
• Squelch sensitivity
• Spurious response rejection
• Clarity variable range
SPECIFICATIONS
:
Receive
Transmit
DSC receive
: TX/RX
RX
DSC
: 50 Ω
: ±10 Hz
: 13.6 V DC ±15% Negative ground
: RX; 3.0 A at Max. output power
TX; 30 A typical at Max. audio output
: –20˚C to +55˚C; –4˚F to +131˚F
: 240(W) 94(H)
: 4.7 kg; 10.4 lb; 165.8 oz
: 150, 60, 20 W PEP
: –62 dB
: 40 dB
: 55 dB
: 600 Ω
:
MODE
J3E, A1A
J2B, F1B
H3E
: 0 dBµVe.m.f. (J2B; 2.1875, 4.2075, 6.3120, 8.4145, 12.5770, 16.8045 MHz)
:
MODE
J3E at 12.230 MHz
H3E at 1.000 MHz
: More than 70 dB
: ±150 Hz
500 kHz–29.9999 MHz
1.6000–2.9999 MHz
6.0000–6.9999 MHz
12.0000–13.9999 MHz
18.0000–19.9999 MHz
25.0000–27.5000 MHz
2.1875 MHz, 4.2075 MHz, 6.3120 MHz, 8.4145 MHz,
12.5770 MHz, 16.8045 MHz
J3E (USB/LSB), J2B (AFSK), F1B (FSK), A1A (CW)
H3E
J2B
238.4(D) mm; 2 ⁄
7 16
FREQUENCY 20 dB SINAD
0.5–1.5999 MHz 30 dBµVe.m.f.
1.6–1.7999 MHz 13 dBµVe.m.f.
1.8–29.9999 MHz
1.6–1.7999 MHz 13 dBµVe.m.f.
1.8–29.9999 MHz
1.5–1.5999 MHz 44 dBµVe.m.f.
1.6–1.7999 MHz 30 dBµVe.m.f.
1.8–3.9999 MHz 24 dBµVe.m.f.
Threshold
Less than +20 dBµV
Less than +30 dBµV
1 - 1
4.0000–4.9999 MHz
8.0000–8.9999 MHz
16.0000–17.9999 MHz
22.0000–22.9999 MHz
(W) 3 ⁄ (H) 9 ⁄ (D) in.
11 16 3 8
10 dB S/N
16 dBµV
–1 dBµV
8 dBµVe.m.f. –6 dBµV
–1 dBµV
8 dBµVe.m.f. –6 dBµV
30 dBµV
16 dBµV
10 dBµV
Tight
Less than +90 dBµV
Less than +110 dBµV
