SECTION 7

7-1 IC-M602

[CHASSIS PARTS]
REF. ORDER
NO. NO.
J1 6510004880 Antenna connector MR-DS-E 01
W1 8900011450 Cable OPC-1175
W2 8900011460 Cable OPC-1176
MP1 8010019070 2577 chassis
MP2 8210019200 2577 rear panel assembly
8210019210 2577 rear panel (A) assembly
MP3 8930058270 2577 F-packing
MP4 8930058260 2577 R-packing
MP5 8930058460 2577 bush plate
MP6 8110007800 2577 module cover
MP7 8930058480 2577 module plate
MP8 8510014900 2577 shield cover
MP9 8930034300 1542 ANT seal
MP10 8930058780 2577 sheet
Screw PH BT M3 × 8 NI-ZU
MP11 8810008660
Screw PH BT M3 × 8 NI-ZU
MP12 8810008660
MP13 8820001210 2438 screw
MP14 8820001210 2438 screw
MP15 8820001210 2438 screw
MP16 8820001210 2438 screw
Screw PH M3 × 10 ZK
MP17 8810004300
MP19 8930052290 O ring (AD)
MP20 8930058450 2577 IC clip
MP21 8930058470 2577 IC plate
MP22 8930049040 Insulation plate
MP23 8930055040 2438 cap
MP25 8930059020 Thermally sheet (AI)
Screw PH BT M3 × 8 NI-ZU
MP26 8810008660
[MAIN UNIT]
REF. ORDER
NO. NO.
W12 7030010860 Jumper MJP-0.6
EP3 6910002160 Shield case BM7
MP1 8510014870 2577 RX-VCO case
MP2 8510014880 2577 TX-VCO case
MP3 8510014890 2577 DBM case
MP4 8510014890 2577 DBM case
MP5 8510015100 2577 shield case
MP6 8930059350 2577 earth plate
MP7 8930014140 Earth spring (D)
[LOGIC BOARD]
REF. ORDER
NO. NO.
S1 2230000250 Switch SPPH22014A
BT1 3020000110 Battery CR2032
DS1 5030002390 LCD HLM7784-010100
MP1 8930058440 2577 LCD holder
MP2 8210019060 2577 reflector
MP3 8930058910 2577 LCD sheet
Screw abbreviations BT: Self-tapping PH: Pan head
ZK: Black
SUS: Stainless

MECHANICAL PARTS AND DISASSEMBLY

DESCRIPTION QTY.
[BLACK]
[WHITE]
DESCRIPTION QTY.
DESCRIPTION QTY.
NI: Nickel
NI-ZU: Nickel-Zinc
[FRONT UNIT]
REF. ORDER
NO. NO.
1 W1 8900011470
1 MP1 8210019180
1 8210019190
MP12 8610011240
1 8610011250
1 MP13 8610011240
1 8610011250
1 MP14 8610011210
1 8610011230
1 MP17 8810008660
1 MP18 8930059200
1 MP19 8930053030
1 MP20 8930058900
1 MP21 8850001980
1 MP22 8930052280
7
3

[CONNECT UNIT]

6
6 REF. ORDER
NO. NO.
2
2
J1 6510022440
2
J2 6510022440
8
J3 6510023320
1
1

[DIAL BOARD]

1
4
REF. ORDER
1
NO. NO.
1
S1 2250000470

[SQL BOARD]

REF. ORDER
NO. NO.
R1 7210002360
1

[VR BOARD]

1
REF. ORDER
1
NO. NO.
1
1
R1 7210003080
1
1
[ACCESSORIES]
1
1
REF. ORDER
NO. NO.
W1 8900011440
P1 6510023310
P2 6510023300
1
MC1 0800006570
0800006580
1
MP1 8950005110
MP2 8610010561
1
8610011260
MP3 8010018860
1
8010019140
1
MP4 8310050900
1
MP5 8810001490
MP6 8850000500
MP7 8850000180
MP8 8810004700
MP9 8930059480
Accessories illustation is shown at the next page.
7 - 1
DESCRIPTION
Cable OPC-1177
2577 front panel assembly
2577 front panel (A) assembly
Knob N295
Knob N295 (A)
Knob N295
Knob N295 (A)
Knob N293
Knob N293 (A)
Screw PH BT M3 × 8 NI-ZU
O ring (AT)
2345 earth plate
Rubber sheet (BB)
Flat washer M10
O ring (AC)
DESCRIPTION
Connector LTW-8MP-C
Connector LTW-8MP-C
Connector LTWD-06PMMP-LC
DESCRIPTION
Switch EVQ-V9C00116E
DESCRIPTION
Variable resistor TP96N97-15F-10KA-1301
DESCRIPTION
Variable resistor TP96N97-15F-10KA-2345
DESCRIPTION
Cable OPC-1174
LTWD-06BFFA-L180
LTWB-03BFFA-L180
HM-136W
HM-136B
2289 mic hanger
2040 knob bolt-1
2040 knob bolt (B)-1
2455 bracket
2455 bracket (A)
2438 warning sticker
Screw PH A M5 × 20 SUS
Spring washer M5 SUS
Flat washer M5 SUS
Screw PH A M3 × 16 SUS
Sponge (GZ)
QTY.
1
[BLACK] 1
[WHITE] 1
[BLACK] 1
[WHITE] 1
[BLACK] 1
[WHITE] 1
[BLACK] 1
[WHITE] 1
7
1
1
2
1
2
QTY.
1
1
1
QTY.
1
QTY.
1
QTY.
1
QTY.
1
1
1
[WHITE] 1
[BLACK] 1
1
[BLACK] 2
[WHITE] 2
[BLACK] 1
[WHITE] 1
1
4
4
4
2
2
