• RC-25 Remote controller
' ' GENERAL
• Microphone impedance
• Audio output power
• Audio output impedance
• Usable temperature range
• Dimension (projections not included)
• Weight
• SP-24 External speaker
' ' GENERAL
• Impedance
• Input power
• Usable temperature range
• Dimension (projections not included)
• Weight
All stated specifications are subject to change without notice or obligation.
: 600 Ω
: More than 5 mW at 16 Ω headphone with 10 % distortion
: 8–16 Ω
: –20˚C to +55˚C; –4˚F to +131˚F
: 220(W)
110(H)
84.4(D) mm; 8
: 570 g; 1.3 lb; 20.1 oz
: 4 Ω
: Rated input;
5 W
Maximum input;
7 W
: –20˚C to +60˚C; –4˚F to +140˚F
: 110(W)
110(H)
84.4(D) mm; 4
: 370 g; 0.82 lb; 13.1 oz
1 - 2
⁄
(W)
4
⁄
(H)
3
⁄
21
32
11
32
5
16
⁄
(H)
4
⁄
(H)
3
⁄
11
32
11
32
5
16
(D) in.
(D) in.
