Icom IC-M802 Service Manual page 35

[MAIN UNIT]
REF ORDER
NO. NO.
C2504 4030009910 S.CERAMIC
C2701 4030011600 S.CERAMIC
C2702 4030011600 S.CERAMIC
C2703 4030011600 S.CERAMIC
C2704 4030011600 S.CERAMIC
C2705 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C2706 4030011600 S.CERAMIC
C2707 4030011600 S.CERAMIC
C2708 4030006880 S.CERAMIC
C2710 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C2711 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C2712 4030006880 S.CERAMIC
C2713 4030006880 S.CERAMIC
C2714 4030009970 S.CERAMIC
C2715 4030010040 S.CERAMIC
C2716 4030011600 S.CERAMIC
C3001 4030008920 S.CERAMIC
C3002 4030008920 S.CERAMIC
C3003 4030008920 S.CERAMIC
C3004 4030008920 S.CERAMIC
C3005 4030008920 S.CERAMIC
C3006 4030011600 S.CERAMIC
C3007 4030007130 S.CERAMIC
C3008 4030011600 S.CERAMIC
C3009 4030011600 S.CERAMIC
C3101 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C3102 4030011600 S.CERAMIC
C3103 4030011600 S.CERAMIC
C3104 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C3201 4030011600 S.CERAMIC
C3202 4030006880 S.CERAMIC
C3302 4030011600 S.CERAMIC
C3303 4030011600 S.CERAMIC
C3304 4030007020 S.CERAMIC
C3305 4030007020 S.CERAMIC
C3306 4030008890 S.CERAMIC
C3307 4030008920 S.CERAMIC
C3308 4030011600 S.CERAMIC
C3309 4030006880 S.CERAMIC
C3310 4030011600 S.CERAMIC
C3311 4030011600 S.CERAMIC
C3601 4030011600 S.CERAMIC
C3602 4030011600 S.CERAMIC
C3603 4030011600 S.CERAMIC
C3604 4030011600 S.CERAMIC
C3605 4030011600 S.CERAMIC
C3606 4030011600 S.CERAMIC
C3901 4030011600 S.CERAMIC
RL2101 6330001320 RELAY
J1 6510007020 CONNECTOR
J51 6510007020 CONNECTOR
J301 6510007020 CONNECTOR
J601 6510007020 CONNECTOR
J1101 6510021650 CONNECTOR
J1102 6510022810 CONNECTOR
J1301 6510022610 S.CONNECTOR 16FMN-BMTTR-A-TBT
J1451 6450000140 CONNECTOR
J1801 6450000170 CONNECTOR
J1901 6510022540 S.CONNECTOR 20FMN-BMTTR-A-TBT
J2051 6510023180 CONNECTOR
J2101 6510007020 CONNECTOR
J2301 6510007020 CONNECTOR
J3001 6510022620 S.CONNECTOR 10FMN-BMTTR-A-TBT
J3601 6510022580 S.CONNECTOR 24FMN-BMTTR-A-TBT
J3602 6510021720 S.CONNECTOR 30FLT-SM1-TB
W501 7030003860 S.JUMPER
W803 7030003860 S.JUMPER
W1011 7030003860 S.JUMPER
W1101 7030003860 S.JUMPER
W1102 7030003860 S.JUMPER
W1227 7030003860 S.JUMPER
W1231 7030003860 S.JUMPER
W1601 7030003860 S.JUMPER
W1701 7030003860 S.JUMPER
W2001 7030003860 S.JUMPER
W2002 7030003860 S.JUMPER
DESCRIPTION
C1608 CH 1H 040B-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 182K-T
C1608 JB 1H 561K-T
C1608 JB 1E 104K-T
C1608 JB 1H 473K-T
C1608 JB 1H 473K-T
C1608 JB 1H 473K-T
C1608 JB 1H 473K-T
C1608 JB 1H 473K-T
C1608 JB 1E 104K-T
C1608 CH 1H 101J-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 CH 1H 120J-T
C1608 CH 1H 120J-T
C1608 JB 1H 273K-T
C1608 JB 1H 473K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
AHY103
TMP-J01X-V6
TMP-J01X-V6
TMP-J01X-V6
TMP-J01X-V6
IMSA-9180B-30B
IMSA-9180B-22B
HSJ0807-01-010
TCS4480-01-1111
TCS7282-01-211
TMP-J01X-V6
TMP-J01X-V6
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
[MAIN UNIT]
REF ORDER
NO. NO.
W2226 7030000010 S.JUMPER
W2227 7030000010 S.JUMPER
W2243 7030000010 S.JUMPER
W2305 7030003860 S.JUMPER
EP1 0910054674 PCB
EP2 0880000900 UNIT BOARD
[PLL UNIT]
REF ORDER
NO. NO.
IC5001 1180001070 S.IC
IC5031 1180001250 S.IC
IC5081 1120002920 S.IC
IC5082 1130006800 S.IC
IC5083 1130007040 S.IC
IC5084 1170000290 S.IC
IC5085 1170000290 S.IC
IC5101 1140007880 S.IC
IC5102 1130004830 S.IC
IC5103 1130004830 S.IC
IC5401 1130009230 S.IC
IC5701 1140004550 S.IC
IC5702 1130004830 S.IC
IC5801 1140004550 S.IC
IC5802 1130004830 S.IC
IC5901 1140004550 S.IC
IC5902 1130004830 S.IC
Q5081 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q5082 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q5083 1590000680 S.TRANSISTOR DTC114EUA T106
Q5084 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q5085 1590000680 S.TRANSISTOR DTC114EUA T106
Q5101 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q5202 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q5281 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q5301 1560000330 S.FET
Q5302 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q5351 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q5401 1590001330 S.TRANSISTOR DTA114EUA T106
Q5521 1560000490 S.FET
Q5553 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q5601 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q5602 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q5603 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q5604 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q5881 1530003150 S.TRANSISTOR 2SC4673D-TD
Q5882 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
D5051 1790001250 S.DIODE
D5081 1790001250 S.DIODE
D5082 1790001250 S.DIODE
D5083 1790001250 S.DIODE
D5084 1790001250 S.DIODE
D5085 1790001250 S.DIODE
D5086 1790001250 S.DIODE
D5101 1750000270 S.DIODE
D5301 1790000540 S.VARICAP
D5302 1790001210 S.DIODE
D5303 1790001210 S.DIODE
D5402 1750000270 S.DIODE
D5521 1720000390 S.VARICAP
FI5101 2020001820 S.CERAMIC
X5251 6050010320 XTAL
5 - 8
DESCRIPTION
MCR10EZHJ JPW (000)
MCR10EZHJ JPW (000)
MCR10EZHJ JPW (000)
ERJ3GE JPW V
B 5722D
EX-2432 #02
DESCRIPTION
TA7805F (TE16L)
TA7808F (TE16L)
ADM202EARN
TC7W08F (TE12L)
TC7W32F (TE12L)
PS2701-1-F3
PS2701-1-F3
TC190G08AF-0046-Z/SC-1246A
TC7SU04F (TE85R)
TC7SU04F (TE85R)
LMX2306TMX
M65343FP/SC1287
TC7SU04F (TE85R)
M65343FP/SC1287
TC7SU04F (TE85R)
M65343FP/SC1287
TC7SU04F (TE85R)
2SK210-GR (TE85R)
2SK508 K52 T2B
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
1SS301 (TE85R)
MA338 (TX)
1SS375-TL
1SS375-TL
1SS301 (TE85R)
KV1470TL
SFECV10M5FA00-R0
CR-604 (32.000 MHz)
S.=Surface mount
