Parts List; Connect Unit; Ant Unit - Icom IC-F4011 Service Manual

SECTION 6.

[ANT UNIT]

REF PARTS
NO. NO.
L601 6200013010 S.COI 0.30-0.9-5TL 10.3N <COMO>
C601 4030017600 S.CER ECJ0EC1H080C

PARTS LIST

DESCRIPTION M.
LOCATION
B
B

[CONNECT UNIT]

H/V REF PARTS
NO. NO.
7.2/12.5 C501 4030017460 S.CER ECJ0EB1E102K
C502 4030016930 S.CER ECJ0EB1A104K
5.8/15.3
J501 6910016390 CON
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6 - 1
DESCRIPTION M.
T
T
IMSA-9230B-1-02Z145-PT1
S.=Surface mount
H/V
LOCATION
8.3/5.3
9.3/5.3
