1.2 Installation

Figure 1-2
Speaker
See the following sections for other installation options:
Section 2.2.1.3, "Running the Singlewire-enabled Speaker with Auxiliary Power"
●
Section 2.2.2.1, "Singlewire-enabled Speaker with Extra Speaker Connection"
●
Section 2.2.2.2, "Singlewire-enabled Speaker with Line Out"
●

1.3 Product Features

Operations Guide
illustrates a typical configurations for the Singlewire-enabled Speaker.
Figure 1-2. Typical Installation
802.3af Compliant Ethernet Switch
1 2 3
Speaker Clock Kit
930320E
4 5 6
IP Phone
● Web-based firmware upgradeable
●
Small footprint
●
High efficiency speaker driver
● PoE 802.3af Enabled (Powered-over-
Ethernet)
● Network and external speaker volume
control
● Auto detect for CyberData Clock kit
Product Overview
Installation
