2.2 Set Up and Test the Speaker

Set up and configure each speaker before you mount it.
CyberData delivers each speaker with the following factory default values:
Parameter
IP Addressing
IP Address
Web Access Username
Web Access Password
Subnet Mask
Default Gateway
a. Default if there is not a DHCP server present.

2.2.1 Connect Power to the Speaker

Figure 2-4
2.2.1.1 Singlewire-enabled Speaker to a 802.3af Compliant PoE Switch
Figure 2-4
switch via a Cat 5 Ethernet cable.
802.3af Switch Class "0"
Operations Guide
Table 2-2. Factory Network Default Settings—Default of Network
a
a
a
through Figure 2-6 illustrates how to connect power to the Singlewire-enabled Speaker.
illustrates how to connect the Singlewire-enabled Speaker to a 802.3af compliant PoE
Figure 2-4. Singlewire-enabled Speaker to a 802.3af Compliant PoE Switch
930320E
Installing the Singlewire-enabled Speaker
Set Up and Test the Speaker
Factory Default Setting
DHCP
10.10.10.10
admin
admin
255.0.0.0
10.0.0.1
Cat 5 Ethernet cable
Speaker
CyberData Corporation
7
