1.2 Installation
Figure 1-2
See the following sections for other installation options:
•
Section 2.2.1.3, "Running the SIP Speaker with Auxiliary Power"
•
Section 2.2.2.1, "SIP Speaker with an External Device"
•
Section 2.2.2.2, "SIP Speaker with Auxiliary Speaker Connection"
•
Section 2.2.2.3, "SIP Speaker with Line Out"
Operations Guide
illustrates a typical configurations for the SIP Speaker.
Figure 1-2. Typical Installation
802.3af/at Compliant Ethernet Switch
SIP Speakers
IP Phone
931181B
Product Overview
Installation
IP PBX Server
CyberData Corporation
3
