CyberData 011120 Installation Quick Reference

Mounting Template
Mounting Template
Speaker Hole Diameter:
Screw Hole Diameter:
Dimensions are in inches [millimeter]
© 2016, CyberData Corporation, ALL RIGHTS RESERVED
120°
VoIP Speaker
7.50 [190.5]
0.1875 [4.75]
4.00 [101.6]
931185B
The IP Endpoint Company
Getting Started
• Create a plan for the locations of your speakers.
• Prior to installation, consult local building and electrical code requirements.
Typical System Installation
Auxiliary Speaker
Parts
(1) Speaker Assembly
Quick Reference Quick Reference
Installation Quick Reference
Auxiliary Analog Speaker
011120*, RAL 9002, Gray White, Standard
011121, RAL 9003, Signal White, Optional
*Replaces the 011072 number.
The Auxiliary Analog Speaker is an option for the CyberData SIP speaker to extend the
coverage area.
When connecting the Auxiliary Analog Speaker to the SIP speaker, the total speaker wattage is
the same. However, by adding this Auxiliary Analog Speaker, additional coverage can be
realized.
The Auxiliary Analog Speaker can be mounted with the same mounting hardware options
available for the SIP Speakers.
802.3af Compliant Ethernet Switch
1 2 3 4 5 6
IP Speaker IP Phone
Clock Kit
(1) Template for Speaker (1) Drop Ceiling Mounting Kit
and Screw Holes*
(3) #8 Nylon Thumb Nuts
(3) #8 Fender Washers
(3) 8-32 x 1 1/4" Mounting
Screws
* See the last page
of this document
931185B © 2016, CyberData Corporation, ALL RIGHTS RESERVED
IP PBX Server
(1) Drywall Mounting Kit
(3) Plastic Ribbed Anchors
(3) #8 Sheet Metal Screws
