1.2 Installation
Figure 1-2
Speaker
See the following sections for other installation options:
•
Section 2.2.1.3, "Running the SIP Speaker with Talk-Back with Auxiliary Power"
•
Section 2.2.2.2, "SIP Speaker with Talk-Back with an External Device"
•
Section 2.2.2.3, "SIP Speaker with Talk-Back with Auxiliary Speaker Connection"
•
Section 2.2.2.4, "SIP Speaker with Talk-Back with Line Out"
Operations Guide
illustrates a typical configurations for the SIP Speaker with Talk-Back.
Figure 1-2. Typical Installation
802.3af/at Compliant Ethernet Switch
Speaker
932005A
Speaker
IP Phone
Product Overview
Installation
IP PBX Server
CyberData Corporation
2
