1.2 Installation

Figure 1-2
Speaker
See the following sections for other installation options:
Section 2.2.1.3, "Running the V2 Speaker with Auxiliary Power"
●
Section 2.2.2.1, "V2 Speaker with Remote Call Button"
●
Section 2.2.2.2, "V2 Speaker with Alert Strobe"
●
Section 2.2.2.3, "V2 Speaker with Extra Speaker Connection"
●
Section 2.2.2.4, "V2 Speaker with Line Out"
●

1.3 Product Features

Operations Guide
illustrates a typical configurations for the VoIP V2 Speaker.
Figure 1-2. Typical Installation
802.3af Compliant Ethernet Switch
1 2 3
Speaker Clock Kit
930274B
4 5 6
IP Phone
●
SIP (RFC 3261) compatible
●
Web-based configuration
● Web-based firmware upgradeable
● Autoprovisioning support
● Small footprint
● High efficiency speaker driver
● PoE 802.3af Enabled (Powered-over-
Ethernet)
● Network and external speaker volume
control
●
Peer-to-peer capability
● User-uploadable ring and alert tones
● Auto detect for CyberData Clock kit
