1 Product Overview
The Voice-over-IP (VoIP) Ceiling Speaker uses a single cable to connect to existing LANs, and
Session Initiation Protocol (SIP) to broadcast messages over your public address system. The small
footprint and low height makes this an ideal speaker to discreetly mount almost anywhere.

1.1 Typical System Installation

Figure 1
system.
PoE VoIP Speakers
Operations Guide
illustrates how the VoIP Ceiling Speakers are normally installed as part of a public address
Figure 1. Public Address System
802.3af PoE compliant Hub
930095F
VoIP Phone
SIP Server
