2.2.2 Installation Options

Figure 2-7
Speaker.
2.2.2.1 Singlewire-enabled Speaker with Extra Speaker Connection
In Figure
analog speaker. While the total speaker wattage is the same, by connecting a low cost analog
speaker, additional coverage can be realized.
Speaker Setup When using the second speaker connection, the digital volume control needs to be set to less than
level 8 while making pages. Some adjustment of this value may be required depending on the
specific PoE switch.
Speaker
AUX POWER (+)
(+12VDC @ 1A)
AUX POWER (-)
Operations Guide
through Figure 2-8
2-7, the Singlewire-enabled Speaker supports an amplified audio output for a second
Figure 2-7. Singlewire-enabled Speaker with Extra Speaker Connection
AUX SPEAKER (-)
AUX SPEAKER (+)
LINE OUT (-)
LINE OUT (+)
J9
J10
illustrates various installation options for the Singlewire-enabled
16 gauge wire and
a maximum length
of 20 feet
930320E
Installing the Singlewire-enabled Speaker
Set Up and Test the Speaker
8 Ohm Analog Speaker
(Part #011120, RAL 9002)
(Part #011121, RAL 9003)
