  • Page 2: Important Safety Instructions

    Powerware and X-Slot are registered trademarks and ConnectUPS is a trademark of Eaton Electrical Inc. Modbus is a registered trademark of Modicon. IBM and AS/400 are registered trademarks of International Business Machines Corp.

  • Page 3: Table Of Contents

    ........... . 3.2.1 Unloading the Powerware 9390 UPS Cabinet from the Pallet ....
  • Page 4 ............. . 7-16 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com...
  • Page 5 ..........9-36 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com...
  • Page 6 ........... . . 12-1 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com...
  • Page 7 ..............EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com...
  • Page 8 Table of Contents This page intentionally left blank. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 9 ........Figure 2-1. Powerware 9390 UPS (40–80 kVA) Cabinet as Shipped on Pallet .
  • Page 10 ..........13-5 viii EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 11: Introduction

    AC power to protect the customer’s load from all nine power failures. The Powerware 9390 UPS is available as a single module or a multiple module parallel system (see paragraph 1.1).

  • Page 12: Basic System Configurations

    The UPS system configuration can be enhanced by adding optional accessories such as a Remote Emergency Power-off (REPO) control, Remote Monitor Panel II (RMP II), or X-Slot ® communication cards. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 13: Using This Manual

    Introduction 1.2 Using This Manual This manual describes how to install and operate the Powerware 9390 UPS (40–80 kVA) cabinet. Read and understand the procedures described in this manual to ensure trouble-free installation and operation. In particular, be thoroughly familiar with the REPO procedure (see page 10-7).

  • Page 14: Conventions Used In This Manual

    In this manual, the term UPS refers only to the UPS cabinet and its internal elements. The term UPS system refers to the entire power protection system – the UPS cabinet, the battery cabinet, and options or accessories installed. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 15: Safety Warnings

    Keep surroundings uncluttered, clean, and free from excess moisture. Observe all DANGER, CAUTION, and WARNING notices affixed to the inside and outside of the equipment. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 16: For More Information

    Introduction 1.5 For More Information Refer to the Powerware 9390 Integrated Battery Cabinet (Models IBC-S and IBC-L) Installation Manual (164201536) for the following additional information: Integrated Battery Cabinet (IBC) installation instructions, including site preparation, planning for installation, wiring, and safety information.

  • Page 17: Section I - Installation

    Section I Installation EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 18 This page intentionally left blank. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 19: Ups Installation Plan And Unpacking

    For the UPS system to operate at peak efficiency, the installation site should meet the environmental parameters outlined in this manual. If the UPS is to be operated at an altitude higher than 1500m (5000 ft), contact your Eaton service representative for important information about high altitude operation. The operating environment must...

  • Page 20: Environmental Considerations

    2.3 Inspecting and Unpacking the UPS Cabinet The cabinet is shipped bolted to a wooden pallet and protected with outer protective packaging material (see Figure 2-1). EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 21: Figure 2-1. Powerware 9390 Ups (40-80 Kva) Cabinet As Shipped On Pallet

    1. Carefully inspect the outer packaging for evidence of damage during transit. C A U T I O N Do not install a damaged cabinet. Report any damage to the carrier and contact your Eaton service representative immediately. 2. Use a forklift or pallet jack to move the packaged cabinet to the installation site, or as close as possible, before unpacking.
  • Page 22 6. After removing the protective covering, inspect the contents for any evidence of physical damage, and compare each item with the Bill of Lading. If damage has occurred or shortages are evident, contact your Eaton service representative immediately to determine the extent of the damage and its impact upon further installation.

  • Page 23: Installing The Ups System

    Additional battery cabinets are supplied without cosmetic covers. Cosmetic covers must be ordered for the UPS cabinet and/or other ancillary cabinets. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 24: Unloading The Powerware 9390 Ups Cabinet From The Pallet

    Installing the UPS System 3.2.1 Unloading the Powerware 9390 UPS Cabinet from the Pallet The UPS cabinet is bolted to a wooden pallet supported by wood skids. To remove the pallet, perform the following procedure: W A R N I N G The UPS cabinet is heavy.

  • Page 25: Figure 3-1. Removing The Front Shipping Bracket On The Powerware 9390 Ups

    Bracket Bolts Pallet Shipping Bracket Bolts Front Anti-tip/Shipping Bracket (note wider base) Figure 3-1. Removing the Front Shipping Bracket on the Powerware 9390 UPS EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 26: Figure 3-2. Removing The Rear Shipping Bracket On The Powerware 9390 Ups

    Removable Skid Shipping Bracket Bolts Pallet Shipping Bracket Bolts Rear Shipping Bracket Figure 3-2. Removing the Rear Shipping Bracket on the Powerware 9390 UPS EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 27: Battery Cabinet Installation

    3.2.3; otherwise, proceed to paragraph 3.2.6. 3.2.2 Battery Cabinet Installation To install the battery cabinet, refer to the Powerware 9390 Integrated Battery Cabinet (Models IBC-S and IBC-L) Installation Manual. After the battery cabinet is installed, return to paragraph 3.2.6 to wire the UPS and battery cabinet.

  • Page 28: Integrated Distribution Cabinet Installation

    3.2.6 to complete the UPS cabinet wiring. 3.2.4 Integrated Accessory Cabinet Installation To install and wire an IAC, refer to the Powerware 9390 Integrated Accessory Cabinet (IAC-B and IAC-T Configurations) Installation and Operation Manual or the Powerware 9390 Integrated Accessory Cabinet (IAC-D Configuration) Installation and Operation Manual.
  • Page 29 11. Disconnect the single-feed jumpers from phase A, B, and C terminals on rectifier input terminals and bypass input terminals. Remove the jumpers from the cabinet. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com...
  • Page 30 22. Route and connect the battery cables between the UPS and battery cabinets in accordance with the instructions in the Powerware 9390 Integrated Battery Cabinet (Models IBC-S and IBC-L) Installation Manual. See Appendix A for UPS cabinet wiring access information.

  • Page 31: Installing Interface Connections

    9. Reinstall the conduit landing plate and install the conduit. 10. To locate the appropriate terminals and review the wiring and termination requirements, see Drawing 164201535-8 starting on page A-34. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 32: Tb1 Battery Cabinet Connections

    10. Proceed to Step 17. 11. If installing interface wiring from the bottom of the cabinet, proceed to Step 12; otherwise, proceed to Step 13. 3-10 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 33: X-Slot Connections

    4. Reinstall the conduit landing plate and install the conduit. 5. Route and install the LAN, telephone, and other cables to the appropriate X-Slot cards. 3-11 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 34: Installing Accessories And Parallel System Control Wiring

    “Installing Options and Accessories.” 3.3 Initial Startup Startup and operational checks must be performed by an authorized Eaton Customer Service Engineer, or the warranty terms specified on page W-1 become void. This service is offered as part of the sales contract for the UPS. Contact service in advance (usually a two-week notice is required) to reserve a preferred startup date.

  • Page 35: Installation Checklist

    - Accessories are mounted in installed locations and wiring is terminated inside the UPS cabinet. (OPTIONAL) - The debris shield covering the UPS cabinet ventilation grill is removed. - Startup and operational checks are performed by an authorized Eaton Customer Service Engineer. 3-13 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com...
  • Page 36 - Pull chain wiring between the UPMs is properly installed. - Adequate workspace exists around the UPMs, parallel tie cabinet, and other cabinets. - Startup and operational checks are performed by an authorized Eaton Customer Service Engineer. 3-14 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com...
  • Page 37 Installing the UPS System Notes _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ 3-15 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 38 Installing the UPS System This page intentionally left blank. 3-16 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 39: Batteries

    Proper disposal of batteries is required. Refer to your local codes for disposal requirements. Never dispose of batteries in a fire. Batteries may explode when exposed to flame. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com...

  • Page 40: Installing Batteries

    C A U T I O N Do not discard waste electrical or electronic equipment (WEEE) in the trash. For proper disposal, contact your local recycling/reuse or hazardous waste center. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 41: Installing A Remote Emergency Power-Off Switch

    5. Remove the screws securing the control panel door and swing the door open. Retain the hardware for later use. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 42 REPO switch rating is 24 Vdc. 1A minimum if supplied by customer. NOTE The REPO switch must be a latching-type switch with a dedicated circuit. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com...
  • Page 43 16. Close the control panel door and secure with the retained hardware. 17. Reinstall the door removed in Step 4 and secure with the retained hardware. 18. Close the door and secure the latch. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 44 Installing a Remote Emergency Power-off Switch This page intentionally left blank. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 45: Installing Options And Accessories

    UPS. Remove the X-Slot cover panel to gain access to the X-Slot. See Drawing 164201535-8 starting on page A-34 for location of the X-Slot communication bay. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 46: Installing Parallel System Control Wiring

    10. Install CAN wiring between UPMs. See Drawing 164201535-8 starting on page A-34 for Powerware Hot Sync CAN Bridge Card location, terminal location, and wiring information. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 47: Installing A Remote Monitor Panel

    NOTE Setup of the Powerware Hot Sync CAN Bridge Card for parallel operation must be performed by an authorized Eaton Customer Service Engineer. Contact service to schedule a date. 13. When all wiring is complete, reinstall the safety shield panels removed in previous steps.

  • Page 48: Installing A Relay Interface Module

    Setup of the Powerware Hot Sync CAN Bridge Card must be performed by an NOTE authorized Eaton Customer Service Engineer. Contact service to schedule a date. 9. To check the operation of the RMP II, ensure that the UPS is supplying the load via inverter or bypass.
  • Page 49 Setup of the Powerware Hot Sync CAN Bridge Card must be performed by an authorized Eaton Customer Service Engineer. Contact service to schedule a date. 9. Contact your Eaton service representative for verification and testing of the RIM II and its connections prior to making connections with J1 through J4 (see Table 6-1 and Drawing 164201535-12 on page A-53).

  • Page 50: Installing A Supervisory Contact Module

    Setup of the Powerware Hot Sync CAN Bridge Card must be performed by an NOTE authorized Eaton Customer Service Engineer. Contact service to schedule a date. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com...

  • Page 51: Figure 6-2. Supervisory Contact Module Ii Tb2

    Supervisory contacts are rated at 2.0A at 28 Vdc or 120 Vac and 0.15A at 115 Vdc. Supervisory contacts require an external power supply. Internal 24 Vdc is not NOTE capable of supplying contact current. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 52 Installing Options and Accessories This page intentionally left blank. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 53: Section Ii - Operation

    Section II Operation EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 54 This page intentionally left blank. 6-10 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 55: Understanding Ups Operation

    Understanding UPS Operation 7.1 Looking Inside the UPS System The Powerware 9390 UPS is a continuous-duty, solid-state, transformerless (at 208 and 480 Vac), three-phase, true online system that provides conditioned and uninterruptible AC power to the UPS system’s output. The UPS supports process control, data processing, telecommunications/PBX, research, and non-patient medical equipment.

  • Page 56: Single Module Reverse Transfer (Rt)

    7.2.1 Single Module RT Modes The Powerware 9390 UPS supports a critical load in three different modes of operation. The UPS can automatically use all three modes, as required. The standard operation...
  • Page 57 The following paragraphs describe the differences in the three UPS operating modes, using block diagrams to show the power flow during each mode of operation. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com...

  • Page 58: Normal Mode - Rt

    The UPS monitors the battery charge condition and reports the status on the control panel. The battery is always connected to the UPS and ready to support the inverter should the utility input become unavailable. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 59 If the UPS suffers an internal failure, it switches automatically to Bypass mode and remains in that mode until the failure is corrected and the UPS is back in service. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com...

  • Page 60: Figure 7-3. Path Of Current Through The Ups In Bypass Mode - Rt

    K3 opens to isolates the inverter. The backfeed protection contactor is normally always closed, ready to support the static switch unless the bypass input source becomes unavailable. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 61 Bypass mode is a normal operating mode, not an alarm condition. However, if the UPS is unable to return to Normal mode following an automatic transfer to Bypass mode, an alarm condition is recorded. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 62: Figure 7-4. Path Of Current Through The Ups In Battery Mode - Rt

    The UPS remains in this operating mode until the input power to the rectifier is again within the specified voltage or frequency acceptance windows. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 63: Multiple Module Parallel System

    7.3 Multiple Module Parallel System Parallel operation extends the normal operation of Powerware 9390 UPS units by offering increased capacity and/or redundant capability. The parallel system continues to maintain power to the critical loads during commercial electrical power brownout, blackout, overvoltage, undervoltage, and out-of-tolerance frequency conditions.

  • Page 64: Multiple Module Parallel System Modes

    UPMs online than required to support the load. 7.3.1 Multiple Module Parallel System Modes Similar to the single module system, the Powerware 9390 UPS parallel system supports a critical load in three different modes of operation. The standard operation modes are: In Normal mode, the paralleled UPMs supply the critical load with clean, filtered power.

  • Page 65: Normal Mode - Parallel

    The parallel system automatically returns to Normal mode when the overload condition is cleared and system operation is restored within specified limits. 7-11 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 66: Bypass Mode - Parallel

    If more modules than can support the load must be taken offline, the load must be transferred to maintenance bypass or shut down. 7-12 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 67 In the Parallel Capacity (N + 0) arrangement, if one unit trips offline and goes to bypass, the remaining units also go to bypass. 7-13 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 68: Battery Mode - Parallel

    The UPMs remain in this operating mode until the input power to the rectifier is again within the specified voltage or frequency acceptance windows. 7-14 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 69: Functional Description

    ABM extends battery life by keeping the batteries charged and performing periodic battery testing. 7-15 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 70: Bypass

    A backfeed contactor is also provided. 7.4.5 Batteries The UPS operates from battery strings from 192 cells (384V nominal) to 240 cells (480V nominal). 7-16 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 71: Using Features And Options

    A ConnectUPS -X Web/SNMP Card is provided as standard equipment and provides remote monitoring through a Web browser interface, e-mail, and a network management system (NMS) using SNMP. See Chapter 13, “Communication,” for additional information. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 72: Advanced Battery Management

    Optional X-Slot connectivity cards are quickly installed at the front of the unit and are hot-pluggable. 8.2 Options and Accessories Contact an Eaton sales representative for information about the following options. 8.2.1 Integrated Battery Cabinets Battery backup protection can be enhanced by equipping the UPS system with up to four Powerware 9390 battery cabinets containing sealed lead-acid, maintenance-free batteries.

  • Page 73: Integrated Accessory Cabinet (Iac-B, Iac-T, And Iac-D)

    Features, Options, and Accessories 8.2.3 Integrated Accessory Cabinet (IAC-B, IAC-T, and IAC-D) The following IACs are designed for use with the Powerware 9390 three-phase Uninterruptible Power Systems: The IAC-B provides maintenance bypass functions. The IAC-T provides parallel tie cabinet or parallel tie cabinet with maintenance bypass functions.

  • Page 74: Remote Monitor Panel

    This symbol indicates that you should not discard waste electrical or electronic equipment (WEEE) in the trash. For proper disposal, contact your local recycling/reuse or hazardous waste center. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 75: Using The Control Panel

    Chapter 10, “UPS Operating Instructions,” for use of the operational controls. When the unit powers up, the screen displays the Eaton | Powerware logo as shown in Figure 9-1. To advance to the Main Menu and Mimic screen, press any control panel pushbutton once.

  • Page 76: Using The Lcd And Pushbuttons

    Set UPS parameters (see paragraphs 9.2.8 and 9.2.9) Control UPS operation (see paragraph 9.3) After approximately 30 minutes, the display screen darkens. To restore the screen, press any pushbutton once. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 77: Using The Main Menu

    02 / 25 / 2004 INPUT BATT STSW OUTPUT BYPASS EVENTS METERS CONTROLS SETUP LOAD OFF Figure 9-3. Main Menu and Mimic Screen (Normal Mode) EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 78: Figure 9-4. Active Events Screen

    BYPASS AC UNDER VOLTAGE NOTICE: BATTERY VOLTAGE LOW NOTICE: NO SYNC ON NOTICE: BYPASS NOT AVAILABLE NOTICE: CONFIGURATION ERROR HISTORY Figure 9-4. Active Events Screen EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 79: Figure 9-5. History Screen

    TO BYPASS COMMAND UPS OFF NOTICE: 5 of 29 02 / 26 / 2004 10 : 20 : 03 . 539 EVENTS Figure 9-5. History Screen EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 80: Figure 9-6. Unit Output Meter Screen

    The Unit Meter screens show the UPS meter readings for the unit (or units, if a parallel system is installed). The default voltage displayed on these screens is phase-to-neutral. However, an authorized Eaton Customer Service Engineer can change the screens to display the voltage phase-to-phase (A-B, B-C, C-A).

  • Page 81: Figure 9-7. Unit Input Meter Screen

    BYPASS --- UNIT FREQ LEAD SYSTEM UNIT Figure 9-8. Unit Bypass Meter Screen EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 82: Figure 9-9. Unit Battery Meter Screen

    The Battery screen displays the battery voltage (Vdc), the battery current (Idc), the minutes of battery time remaining, and battery temperature. Battery temperature must be set up by an authorized Eaton Customer Service Engineer. When battery life decreases to less than 20%, Check Battery is displayed.

  • Page 83: Figure 9-11. Battery Discharge Log Summary Screen

    07/28/2005 AVERAGE TIME ON BATTERY ** M ** S TOTAL TIME ON BATTERY ** H ** M Figure 9-11. Battery Discharge Log Summary Screen EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 84: Figure 9-12. Battery Discharge Log Screen

    ** M ** S LOAD WHEN ON BATTERY ***.** KW END VOLTAGE : ***.** V RESET SUMMARY Figure 9-12. Battery Discharge Log Screen 9-10 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 85: Figure 9-13. Kw Demand Log Summary Screen

    TOTAL TIME OVER LIMIT ** MINUTES TOTAL KWH USED OVER LIMIT *** . ** KWH SETUP Figure 9-13. KW Demand Log Summary Screen 9-11 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 86: Figure 9-14. Kw Demand Log Screen

    TIME OVER LIMIT 2 MINUTES KWH USED OVER LIMIT *** . ** NUM TIMES OVER THIS INTERVAL RESET SUMMARY Figure 9-14. KW Demand Log Screen 9-12 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 87: Figure 9-15. Current Kw Demand Log Setup Screen 1

    CURRENT KW DEMAND LOG SETUP TIME INTERVAL MONITORED 3 MINUTES MAXIMUM LEVEL (KW) *** KW CHANGE Figure 9-15. Current KW Demand Log Setup Screen 1 9-13 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 88: Figure 9-16. Current Kw Demand Log Setup Screen 2

    CURRENT KW DEMAND LOG SETUP TIME INTERVAL MONITORED MAXIMUM LEVEL (KW) SELECT Figure 9-16. Current KW Demand Log Setup Screen 2 9-14 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 89: Figure 9-17. Time Interval Monitored Setup Screen

    The Time Interval Monitored Setup Save screen is displayed. TIME INTERVAL MONITORED SETUP 0000 DONE Figure 9-17. Time Interval Monitored Setup Screen 9-15 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 90: Figure 9-18. Time Interval Monitored Setup Save Screen

    Current KW Demand Log Setup screen 2 displays. If RETRY is pressed, the Time Interval Monitored Setup screen is redisplayed. TIME INTERVAL MONITORED SETUP 0000 SAVE RETRY ABORT Figure 9-18. Time Interval Monitored Setup Save Screen 9-16 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 91: Figure 9-19. Maximum Level (Kw) Setup Screen

    The Maximum Level (KW) Setup Save screen is displayed. MAXIMUM LEVEL (KW) SETUP 0000 DONE Figure 9-19. Maximum Level (KW) Setup Screen 9-17 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 92: Figure 9-20. Maximum Level (Kw) Setup Save Screen

    Current KW Demand Log Setup screen 2 displays. If RETRY is pressed, the Maximum Level (KW) Setup screen is redisplayed. MAXIMUM LEVEL (KW) SETUP 0000 SAVE RETRY ABORT Figure 9-20. Maximum Level (KW) Setup Save Screen 9-18 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 93: Figure 9-21. Maximum Current Log Summary Screen

    MAXIMUM % OF FULL LOAD *** . ** % TOTAL TIME OVER LIMIT ** MINUTES SETUP Figure 9-21. Maximum Current Log Summary Screen 9-19 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 94: Figure 9-22. Maximum Current Log Screen (Three-Phase Measurement)

    *** . ** % TIME OVER LIMIT 2 MINUTES NUM TIMES OVER THIS INTERVAL RESET SUMMARY Figure 9-22. Maximum Current Log Screen (Three-Phase Measurement) 9-20 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 95: Figure 9-23. Maximum Current Log Screen (Individual Phase Measurement)

    3 MINUTES MAXIMUM % OF FULL LOAD *** % LEVEL BASED ON 3 PHASE AVERAGE CHANGE Figure 9-24. Maximum Current Log Setup Screen 1 9-21 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 96: Figure 9-25. Maximum Current Log Setup Screen 2

    MAXIMUM CURRENT LOG SETUP TIME INTERVAL MONITORED MAXIMUM % OF FULL LOAD CALCULATION METHOD SELECT Figure 9-25. Maximum Current Log Setup Screen 2 9-22 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 97: Figure 9-26. Time Interval Monitored Setup Screen

    The Time Interval Monitored Setup Save screen is displayed. TIME INTERVAL MONITORED SETUP 0000 DONE Figure 9-26. Time Interval Monitored Setup Screen 9-23 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 98: Figure 9-27. Time Interval Monitored Setup Save Screen

    Maximum Current Log Setup screen 2 displays. If RETRY is pressed, the Time Interval Monitored Setup screen is redisplayed. TIME INTERVAL MONITORED SETUP 0000 SAVE RETRY ABORT Figure 9-27. Time Interval Monitored Setup Save Screen 9-24 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 99: Figure 9-28. Maximum % Of Full Load Setup Screen

    The Maximum % of Full Load Setup Save screen is displayed. MAXIMUM % OF FULL LOAD SETUP DONE Figure 9-28. Maximum % of Full Load Setup Screen 9-25 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 100: Figure 9-29. Maximum % Of Full Load Setup Save Screen

    Full Load Setup screen is redisplayed. MAXIMUM % OF FULL LOAD SETUP SAVE RETRY ABORT Figure 9-29. Maximum % of Full Load Setup Save Screen 9-26 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 101: Figure 9-30. Calculation Method Setup Screen

    MAXIMUM CURRENT LOG SETUP LEVEL BASED ON 3 PHASE AVERAGE LEVEL BASED ON INDIVIDUAL PHASES SELECT Figure 9-30. Calculation Method Setup Screen 9-27 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 102: Figure 9-31. System Meters Screen

    The System Meters screens show the total system and individual UPS unit meter readings from any unit, when a parallel system is installed. The default voltage displayed on these screens is phase-to-neutral. However, an authorized Eaton Customer Service Engineer can change the screens to display the voltage phase-to-phase (A-B, B-C, C-A).

  • Page 103: Figure 9-32. Total System Output Meter Screen

    PF is calculated from the total values for the kVA and kW. OUTPUT TOTAL SYSTEM FREQ LEAD SYSTEM UNIT Figure 9-32. Total System Output Meter Screen 9-29 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 104: Figure 9-33. Output Unit X Meter Screen

    UPS, as well as the kVA, kW, and power factor measurements for the selected unit. OUTPUT UNIT X FREQ LEAD SYSTEM UNIT Figure 9-33. Output Unit X Meter Screen 9-30 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 105: Figure 9-34. Input Unit X Meter Screen

    BYPASS UNIT X FREQ LEAD SYSTEM UNIT Figure 9-35. Bypass Unit X Meter Screen 9-31 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 106: Figure 9-36. Battery Unit X Meter Screen

    The Battery screen displays the battery voltage (Vdc), the battery current (Idc), the minutes of battery time remaining, and battery temperature. Battery temperature must be set up by an authorized Eaton Customer Service Engineer When battery life decreases to less than 20%, Check Battery is displayed.

  • Page 107: Figure 9-38. System Setup Level 0 Screen

    SELECT pushbutton to display the function screen. SYSTEM SETUP LEVEL 0 ENTER PASSWORD CONTRAST ADJUST VERSIONS UNIT TYPE SELECT Figure 9-38. System Setup Level 0 Screen 9-33 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 108: Figure 9-39. Contrast Adjust Screen

    Setup screen displays. To return to the System Setup screen without saving the setting, press the pushbutton. CONTRAST ADJUST SAVE Figure 9-39. Contrast Adjust Screen 9-34 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 109: Figure 9-40. Versions Screen

    The Unit Type screen provides the model, CTO, and serial numbers of the UPS unit. Figure 9-41 shows the Unit Type screen. To return to the System Setup screen, press the pushbutton. UNIT TYPE MODEL: POWERWARE 9390 CTO: 0000000000000000 SERIAL: 0000000000000000 Figure 9-41.

  • Page 110: Figure 9-42. Enter Password Screen

    DONE pushbutton. The System Setup Level 1 menu screen is displayed. The default password is L1. ENTER PASSWORD DONE Figure 9-42. Enter Password Screen 9-36 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 111: Figure 9-43. System Setup Level 1 Screen

    SYSTEM SETUP LEVEL 1 LOG OUT ENTER PASSWORD CHANGE PASSWORD ENTER PASS- CONTRAST ADJUST WORD VERSIONS UNIT TYPE SELECT Figure 9-43. System Setup Level 1 Screen 9-37 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 112: Figure 9-44. Change Password Screen

    Once the new password is entered, press the DONE pushbutton. The Change Password Save screen is displayed. CHANGE PASSWORD OLD: NEW: DONE Figure 9-44. Change Password Screen 9-38 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 113: Figure 9-45. Change Password Save Screen

    System Setup screen displays. If RETRY is pressed, the Change Password screen is redisplayed. CHANGE PASSWORD OLD: NEW: ABORT SAVE RETRY Figure 9-45. Change Password Save Screen 9-39 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 114: Figure 9-46. Time Format Screen

    Set Date and Time screen. To return to the System Setup screen, press the pushbutton. TIME FORMAT SETUP MM/DD/YYYY DD/MM/YYYY SELECT Figure 9-46. Time Format Screen 9-40 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 115: Figure 9-47. Set Date And Time Mm/Dd/Yyyy Screen

    System Setup screen, select the pushbutton. SET DATE AND TIME MM/DD/YYYY MONTH DATE YEAR HOUR MINUTE SAVE 2004 Figure 9-47. Set Date and Time MM/DD/YYYY Screen 9-41 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 116: Figure 9-48. Set Date And Time Dd/Mm/Yyyy Screen

    System Setup screen, select the pushbutton. SET DATE AND TIME DD/MM/YYYY DATE MONTH YEAR HOUR MINUTE SAVE 2004 Figure 9-48. Set Date and Time DD/MM/YYYY Screen 9-42 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 117: Figure 9-49. Com Port Setup Screen

    SELECT pushbutton. To return to the System Setup screen, press the pushbutton. COM PORT SETUP COM 1 COM 2 COM 3 SELECT Figure 9-49. COM Port Setup Screen 9-43 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 118: Figure 9-50. Com Setup Screen

    Once the action is completed, the COM Port Setup screen appears. COM 1 SETUP BAUD RATE 19200 DATA BITS STOP BITS PARITY NONE ABORT SAVE Figure 9-50. COM Setup Screen 9-44 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 119: Figure 9-51. System Controls Screen 1

    System Controls screens. SYSTEM CONTROLS MAINTENANCE BYPASS BYPASS ONLINE POWER MODULE (PM) CHARGER LOAD OFF NORMAL BYPASS Figure 9-51. System Controls Screen 1 9-45 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 120: Figure 9-52. System Controls Screen 2

    On and Off. For detailed information about using the System Controls, see Chapter 10, “UPS Operating Instructions.” 9-46 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 121: Figure 9-53. Load Off Screen

    Chapter 10, “UPS Operating Instructions.” HOLD LOAD OFF BUTTON FOR 3 SECONDS TO TURN OFF LOAD CANCEL LOAD OFF Figure 9-53. Load Off Screen 9-47 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 122: Reading The Status Indicators

    The indicator flashes until acknowledged by pressing any control panel pushbutton once. For more information about audible horns, see “System Event Horns” on page 12-1. 9-48 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 123: Ups Operating Instructions

    Normal mode. The status indicator on the UPS control panel indicates the UPS is in Bypass mode. If Auto Bypass is not enabled, the UPS output remains off until the UPS transfers to Normal mode. 10-1 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 124: Starting The Ups In Bypass Mode

    The critical load is immediately supplied by the bypass source, in Bypass mode. 7. The UPS is now operating in Bypass mode and the BYPASS status indicator is illuminated. 10-2 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 125: Starting The Power Module

    The UPS transfers to Bypass mode and the critical load is immediately supplied by the bypass source. If the bypass source is not available, the power processor remains on and an alarm sounds. 10-3 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 126: Transfer From Bypass To Normal Mode

    The bypass source supplies the critical load. W A R N I N G Power is present inside the UPS cabinets. 10-4 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 127: Ups And Critical Load Shutdown

    System Controls Screen 2. 3. Press the CHGR ON or CHGR OFF pushbutton on the System Controls menu bar to toggle the charger on or off. 10-5 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 128: Using The Ups Load Off Pushbutton

    Do not attempt to restart the system after Load Off until the cause of the shutdown has been identified and cleared. 3. To restart the UPS after pressing the LOAD OFF pushbutton, follow the procedure in paragraph 10.1.1 or 10.1.2. 10-6 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 129: Using The Remote Emergency Power-Off Switch

    2. To restart the UPS after using the REPO pushbutton, reset the REPO switch and then follow the procedure in paragraph 10.1.1 or 10.1.2. 10-7 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 130: Multiple Module Parallel Operation

    Normal mode. 9. The UPMs are now operating in Normal mode and the NORMAL status indicator on each UPM is illuminated. 10-8 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 131: Starting The Parallel System In Bypass Mode

    The critical load is immediately supplied by the bypass source, in Bypass mode. 7. The UPMs are now operating in Bypass mode and the BYPASS status indicator on each UPM is illuminated. 10-9 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 132: Transfer Parallel System From Normal To Bypass Mode

    3. The UPMs are now operating in Normal mode, and the NORMAL status indicator on each UPM is illuminated. The power module (PM) status indicates ONLINE on each UPM. 10-10 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 133: Single Upm Shutdown

    5. Press the CONTROLS pushbutton on the main menu bar of the UPM. The System Controls screen appears. 6. On the System Controls screen, the power module (PM) status should indicate SHUTDOWN. 10-11 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 134: Parallel System And Critical Load Shutdown

    The bypass source supplies the critical load. 6. Repeat Steps 2, 4, and 5 for each UPM, except the last UPM. 10-12 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 135: Using The Ups Load Off Pushbutton

    When LOAD OFF is selected and held for three seconds, the input, output, and bypass backfeed contactors open, the battery breaker or disconnect is tripped, and the power module is turned off. 10-13 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 136: Using The Parallel System Remote Emergency Power-Off Switch

    2. To restart the UPMs after using the REPO pushbutton, reset the REPO switch and then follow the procedure in paragraph 10.2.1 or 10.2.2. 10-14 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 137: General Purpose Relay Contact

    UPS horn may not be heard immediately. C A U T I O N Contacts should not be operated in excess of 120 Vac @ 5A maximum. 11-1 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 138: Figure 11-1. Remote Monitor Panel Ii

    Figure 11-1 shows an RMP II. Figure 11-1. Remote Monitor Panel II 11-2 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 139 The UPS is preparing to shut down because the UPS is in Battery mode and the DC voltage is approaching its low limit. This indicator is accompanied by a horn. 11-3 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 140: Figure 11-2. Relay Interface Module Ii

    UTILITY FAILURE Pins 6 and 15 Contacts are closed when Utility Failure is detected. 11-4 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 141: Figure 11-3. Supervisory Contact Module Ii

    TB2-10 through TB2-12 ON BATTERY TB2-13 through TB2-15 UPS ALARM TB2-16 through TB2-18 ON BYPASS TB2-19 through TB2-21 SHUTDOWN IMMINENT TB2-22 through TB2-24 11-5 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 142 Using Features and Options This page intentionally left blank. 11-6 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 143: Responding To System Events

    The messages are divided into four categories: alarms, notices, status, and commands. The following tables contain the events displayed on the Events screen of the control panel. 12-1 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 144 *Log codes indicate where the UPS records the event: H = History log; HA = History and Active logs; and A = Active log only. 12-2 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 145 *Log codes indicate where the UPS records the event: H = History log; HA = History and Active logs; and A = Active log only. 12-3 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 146 *Log codes indicate where the UPS records the event: H = History log; HA = History and Active logs; and A = Active log only. 12-4 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 147 *Log codes indicate where the UPS records the event: H = History log; HA = History and Active logs; and A = Active log only. 12-5 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 148 *Log codes indicate where the UPS records the event: H = History log; HA = History and Active logs; and A = Active log only. 12-6 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 149 *Log codes indicate where the UPS records the event: H = History log; HA = History and Active logs; and A = Active log only. 12-7 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 150 *Log codes indicate where the UPS records the event: H = History log; HA = History and Active logs; and A = Active log only. 12-8 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 151 *Log codes indicate where the UPS records the event: H = History log; HA = History and Active logs; and A = Active log only. 12-9 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 152 Responding to System Events This page intentionally left blank. 12-10 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 153: Communication

    Chapter 13 Communication This chapter describes the communication features of the Powerware 9390 40–80 kVA UPS and provides information about connecting hardware and using Terminal mode. 13.1 X-Slot Cards The Powerware 9390 UPS has a standard, factory-installed X-Slot communication bay with two slots.

  • Page 154: Figure 13-1. Optional X-Slot Cards

    Industrial Relay Card Figure 13-1. Optional X-Slot Cards 13.2 LanSafe Power Management Software Each Powerware 9390 UPS ships with LanSafe Power Management Software. To begin installing LanSafe software, see the instructions accompanying the Powerware Software Suite CD. LanSafe software uses an RS-232 serial link to communicate with the UPS. The software provides up-to-date graphics of UPS power and system data and power flow, a complete record of critical power events, and notification of important UPS or power information.

  • Page 155: Terminal Mode

    See Chapter 9, “Using the Control Panel,” for instructions on navigating the control panel. 13-3 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 156: Event History Log

    If a port is operating in Terminal mode and is connected to a computer, you can press [Esc] [H] to print the entire log with a firmware version header. 13-4 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 157: Figure 13-2. Sample Event History Log

    03/12/2004 14:17:25.557 ALARM: Battery Under Voltage OK 03/12/2004 14:19:01.899 CMD: PPU On Command 03/12/2004 14:19:04.089 STATUS: K1 (Input) Closed Figure 13-2. Sample Event History Log 13-5 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 158 Communication This page intentionally left blank. 13-6 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 159: Maintaining The Ups System

    Eaton service representative. If the string requires service, refer to the battery manufacturer’s operating manual for instructions on battery maintenance or contact your Eaton service representative. Observe these precautions when working on or around batteries: Remove watches, rings, or other metal objects.

  • Page 160: Performing Preventive Maintenance

    2. Ensure the air intakes (vents on the front doors) and exhaust opening (on top of the UPS cabinet sections) are not blocked. 14-2 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 161: Monthly Maintenance

    3. Record the check results and any corrective actions in a suitable log. 14.2.3 ANNUAL Maintenance Annual preventive maintenance should be performed only by authorized service personnel familiar with maintenance and servicing of the UPS system. Contact your Eaton service representative for more information about service offerings. 14.2.4 BATTERY Maintenance Contact your Eaton service representative for battery maintenance.
  • Page 162 Maintaining the UPS System This page intentionally left blank. 14-4 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 163: Product Specifications

    The UPS systems are housed in free-standing cabinets with safety shields behind the doors. The UPS systems are available in 50/60 Hz with various output power ratings. System Models Frequency Powerware 9390-40/40 40 kVA 50/60 Hz Powerware 9390-80/40 40 kVA...

  • Page 164: Ups System Output

    Meets IEC 801-2 specifications. Withstands up to 25 kV pulse without damage and with no disturbance or adverse effect to (ESD) Immunity the critical load. 15-2 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 165: Multiple Module Parallel Specifications

    220 Vac for operation from 187 Vac to 242 Vac 480 Vac for operation from 408 Vac to 528 Vac Operating Output Current See Appendix A, Table P through Table S. 15-3 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 166 Product Specifications This page intentionally left blank. 15-4 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 167 Installation Information The information in this appendix is helpful during the planning and installation of the UPS system. This appendix contains the following drawings: 164201535-1 Typical Powerware 9390 UPS System 164201535-2 Physical Features and Requirements 164201535-3 UPS System Oneline Configurations...

  • Page 168: Battery Cabinet

    Installation Information BATTERY CABINET UPS CABINET DESCRIPTION: TYPICAL POWERWARE 9390 UPS SYSTEM DRAWING NO: SHEET: 164201535---1 1 of 1 REVISION: DATE: 111504 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 169 Table A. UPS Cabinet Weight Weight Voltage kg (lb) Model Input Output Shipping Installed Point Loading Powerware 9390---40/40 208V/220V 208V/220V 263 (580) 241 (530) 4 at 60.3 (133) Powerware 9390---40/40 480V 480V 231 (508) 208 (458) 4 at 52.2 (115)
  • Page 170 Ventilation required for cooling air exhaust: approximately 472 liter/sec (1000 cfm). DESCRIPTION: PHYSICAL FEATURES AND REQUIREMENTS DRAWING NO: SHEET: 164201535---2 2 of 2 REVISION: DATE: 081505 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 171 Single-Feed or Dual-Feed 9390---80/60 3+1 and 4+0 Configurations 9390---80/80 DESCRIPTION: UPS SYSTEM ONELINE CONFIGURATIONS DRAWING NO: SHEET: 164201535---3 1 of 1 REVISION: DATE: 081505 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 172 BREAKER (K3) FUSE INVERTER BATTERY CABINET UPS CABINET (Optional) POWERWARE 9390 40–80 KVA UPS SYSTEM 208V/220V INPUT AND 208V/220V OUTPUT 480V INPUT AND 480V OUTPUT SINGLE-FEED OR DUAL-FEED NOTE: 1. Remove jumper for dual-feed. DESCRIPTION: UPS SYSTEM ONELINE DRAWING DRAWING NO:...
  • Page 173 DO NOT use one feed or a single-feeder breaker to supply both the UPS and the maintenance bypass. DESCRIPTION: UPS SYSTEM ONELINE DRAWING DRAWING NO: SHEET: 164201535---4 2 of 5 REVISION: DATE: 081505 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 174 UPS SYSTEM ONELINE DRAWING DRAWING NO: SHEET: 3 of 5 164201535---4 3. See Note 27 on page A ---21 for neutral bonding instructions. REVISION: DATE: 081505 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 175 UPS SYSTEM ONELINE DRAWING DRAWING NO: SHEET: 4 of 5 3. See Note 27 on page A ---21 for 164201535---4 neutral bonding instructions. REVISION: DATE: 081505 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 176 UPS SYSTEM ONELINE DRAWING DRAWING NO: SHEET: 5 of 5 3. See Note 27 on page A ---21 for 164201535---4 neutral bonding instructions. REVISION: DATE: 081505 A-10 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 177 Installation Information Table E. INPUT/OUTPUT Ratings & External Wiring Requirements for the Powerware 9390---40/40 and 9390---80/40 Units Rating 50/60 Hz Basic Unit Rating at 0.9 lagging pF load Input and Bypass Input VOLTS 208/220 Output VOLTS 208/220 AC Input to UPS Rectifier (0.98 min. pF)
  • Page 178 Installation Information Table F. INPUT/OUTPUT Ratings & External Wiring Requirements for the Powerware 9390---80/50 Units Rating 50/60 Hz Basic Unit Rating at 0.9 lagging pF load Input and Bypass Input VOLTS 208/220 Output VOLTS 208/220 AC Input to UPS Rectifier (0.98 min. pF)
  • Page 179 3 of 5, 4 of 5, and 5 of 5. C A U T I O N DELTA SOURCES (TN-S) - The Powerware 9390 UPS system can be operated only from a delta supply source unless that source is fully floating and only if the neutral-forming transformer kit (PN 103005400) is installed in the UPS.
  • Page 180 3 of 5, 4 of 5, and 5 of 5. DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 4 of 17 164201535---5 REVISION: DATE: 032406 A-14 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 181 Table K for conduit requirements. Drawing 164201535 ---7 shows the location of the power cable terminals inside the UPS cabinet. Table I. UPS Cabinet Power Cable Terminations for the Powerware 9390---40/40, 9390---80/40, 9390---80/50, 9390---80/60, and 9390---80/80 (208V/220V Input and 208V/220V Output)
  • Page 182 Installation Information Table J. UPS Cabinet Power Cable Terminations for the Powerware 9390---40/40, 9390---80/40, 9390---80/50 9390---80/60, and 9390---80/80 (480V Input and 480V Output) Tightening Size of Pressure Type Terminal Function Terminal Function Torque Termination Screw Nm (lb in) AC Input to UPS Rectifier...
  • Page 183 Table K. All Powerware 9390 products can accommodate a double size neutral. Conduit sizes were chosen from NEC Table C1, type letters RHH, RHW, RHW-2, TW, THW, THHW, THW-2.
  • Page 184 (A, B, C, Neut, Gnd) Battery (Positive), (Negative), Gnd DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 164201535---5 8 of 17 REVISION: DATE: 081505 A-18 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 185 Table M. Table L. Maximum Input Circuit Breaker Ratings Input Voltage Rating UPS Model 208V/220V 480V 80% Rated 175A Powerware 9390---40/40 Powerware 9390---80/40 100% Rated 150A 80% Rated 225A 100A Powerware 9390---80/50 100% Rated...
  • Page 186 Table M. Maximum Bypass and Output Circuit Breaker Ratings Output Voltage Rating UPS Model 208V/220V 480V 80% Rated 175A Powerware 9390---40/40 Powerware 9390---80/40 100% Rated 150A 80% Rated 225A 100A Powerware 9390---80/50 100% Rated...
  • Page 187 UPS. C A U T I O N DELTA SOURCES (TN-S) - The Powerware 9390 UPS system can be operated only from a delta supply source unless that source is fully floating and only if the neutral-forming transformer kit (PN 103005400) is installed in the UPS.
  • Page 188 Setup of the CAN Bridge card for parallel operation must be performed by an authorized Eaton Customer Service Engineer . Contact service to schedule a date. For parallel system circuit breaker ratings, see appropriate information in Table O.
  • Page 189 Installation Information Table P. INPUT/OUTPUT Ratings for Powerware 9390---40/40 and 9390---80/40 Parallel Systems Configuration Units Rating 50/60 Hz Basic Unit Rating at 0.9 lagging pF load Input and Bypass Input VOLTS 208/220 Output VOLTS 208/220 AC Input from UPM Amps...
  • Page 190 Installation Information Table Q. INPUT/OUTPUT Ratings for Powerware 9390---80/50 Parallel System Configuration Units Rating 50/60 Hz Basic Unit Rating at 0.9 lagging pF load Input and Bypass Input VOLTS 208/220 Output VOLTS 208/220 AC Input from UPM Amps 139/131 Full Load Current for each Module...
  • Page 191 Installation Information Table R. INPUT/OUTPUT Ratings for Powerware 9390---80/60 Parallel System Configuration Units Rating 50/60 Hz Basic Unit Rating at 0.9 lagging pF load Input and Bypass Input VOLTS 208/220 Output VOLTS 208/220 AC Input from UPM Amps 167/158 Full Load Current for each Module...
  • Page 192 Installation Information Table S. INPUT/OUTPUT Ratings for Powerware 9390---80/80 Parallel System Configuration Units Rating 50/60 Hz Basic Unit Rating at 0.9 lagging pF load Input and Bypass Input VOLTS 208/220 Output VOLTS 208/220 AC Input from UPM Amps 222/210 Full Load Current for each Module...
  • Page 193 UPM 3 Outputs from UPMs Battery UPM 4 Battery DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 164201535---5 17 of 17 REVISION: DATE: 093004 A-27 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 194 (REMOVE PANELS TO DRILL OR PUNCH CONDUIT HOLES.) TOP VIEW DESCRIPTION: CONDUIT AND WIRE ENTRY LOCATIONS DRAWING NO: SHEET: 164201535---6 1 of 2 REVISION: DATE: 111504 A-28 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 195 AS REQUIRED, TO ROUTE WIRES BETWEEN CABINETS. DESCRIPTION: CONDUIT AND WIRE ENTRY LOCATIONS DRAWING NO: SHEET: 164201535---6 2 of 2 REVISION: DATE: 111504 A-29 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 196 UPS POWER TERMINAL LOCATIONS opened to gain access to DRAWING NO: SHEET: 164201535---7 1 of 4 terminals. REVISION: DATE: 032406 A-30 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 197 (E12) OUTPUT TERMINALS 208V INPUT AND 208V OUTPUT DESCRIPTION: UPS POWER TERMINAL LOCATIONS DRAWING NO: SHEET: 164201535---7 2 of 4 REVISION: DATE: 111504 A-31 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 198 UPS POWER TERMINAL LOCATIONS terminals must be removed or DRAWING NO: SHEET: 164201535---7 3 of 4 opened to gain access to terminals. REVISION: DATE: 032406 A-32 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 199 FROM BATTERY --- (E5) 480V INPUT AND 480V OUTPUT DESCRIPTION: UPS POWER TERMINAL LOCATIONS DRAWING NO: SHEET: 164201535---7 4 of 4 REVISION: DATE: 081505 A-33 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 200 TO COMMON SIDE OF ISOLATED RELAY CONTACT. INTERFACE WIRING INSTALLATION DESCRIPTION: NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 164201535---8 1 of 13 REVISION: DATE: 032406 A-34 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 201 NOTES AND TERMINAL LOCATIONS opened to gain access to DRAWING NO: SHEET: 2 of 13 terminals. 164201535---8 REVISION: DATE: 032406 A-35 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 202 EPO contact is not used. DESCRIPTION: INTERFACE WIRING INSTALLATION NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 3 of 13 164201535---8 REVISION: DATE: 032406 A-36 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 203 2. The building alarms can be programmed to display the alarm functional name. INTERFACE WIRING INSTALLATION DESCRIPTION: NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 4 of 13 164201535---8 REVISION: DATE: 081505 A-37 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 204 UPS is in Normal mode. INTERFACE WIRING INSTALLATION DESCRIPTION: NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 5 of 13 164201535---8 REVISION: DATE: 032406 A-38 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 205 The REPO switch must be a latching-type switch with a dedicated circuit. INTERFACE WIRING INSTALLATION DESCRIPTION: NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 6 of 13 164201535---8 REVISION: DATE: 032406 A-39 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 206 Minimum Wire Size: 22 AWG for auxiliary contact ratings. INTERFACE WIRING INSTALLATION DESCRIPTION: NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 7 of 13 164201535---8 REVISION: DATE: 032406 A-40 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 207 24 Vdc at 6A Maximum INTERFACE WIRING INSTALLATION DESCRIPTION: NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 8 of 13 164201535---8 REVISION: DATE: 081505 A-41 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 208 NOTES AND TERMINAL LOCATIONS NOTE: All interface wiring is to be provided DRAWING NO: SHEET: 9 of 13 164201535---8 by the customer. REVISION: DATE: 081505 A-42 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 209 (IF INSTALLED) PARALLEL SYSTEM CAN WIRING INTERFACE WIRING INSTALLATION DESCRIPTION: NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 10 of 13 164201535---8 REVISION: DATE: 081505 A-43 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 210: Parallel System

    INTERFACE WIRING INSTALLATION PULL CHAIN WIRING NOTES AND TERMINAL LOCATIONS (WITHOUT MOB AUX DRAWING NO: SHEET: 11 of 13 164201535---8 CONTACTS) REVISION: DATE: 032406 A-44 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 211: Supervisory Contact Module

    SUPERVISORY CONTACT MODULE TERMINAL LOCATIONS DESCRIPTION: INTERFACE WIRING INSTALLATION NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 12 of 13 164201535---8 REVISION: DATE: 111504 A-45 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 212 RMP II, RIM II, OR SCM II TWISTED PAIR DESCRIPTION: INTERFACE WIRING INSTALLATION NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 13 of 13 164201535---8 REVISION: DATE: 111504 A-46 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...

  • Page 213: Front View

    FRONT VIEW RIGHT SIDE VIEW DESCRIPTION: UPS CABINET DIMENSIONS DRAWING NO: SHEET: 164201535---9 1 of 4 REVISION: DATE: Dimensions are in millimeters [inches] 111504 A-47 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 214 TOP VIEW BOTTOM VIEW DESCRIPTION: UPS CABINET DIMENSIONS DRAWING NO: SHEET: 2 of 4 164201535---9 REVISION: DATE: Dimensions are in millimeters [inches] 111504 A-48 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 215 BOTTOM VIEW with OPTIONAL FLOOR MOUNTING BRACKETS DESCRIPTION: UPS CABINET DIMENSIONS DRAWING NO: SHEET: 3 of 4 164201535---9 REVISION: DATE: 111504 Dimensions are in millimeters [inches] A-49 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 216 BOTTOM VIEW with OPTIONAL SEISMIC MOUNTING BRACKETS DESCRIPTION: UPS CABINET DIMENSIONS DRAWING NO: SHEET: 4 of 4 164201535---9 REVISION: DATE: 081505 Dimensions are in millimeters [inches] A-50 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 217 Minimum wire size #22 AWG. OPTIONAL REMOTE EMERGENCY DESCRIPTION: POWER-OFF DRAWING NO: SHEET: 164201535---10 1 of 1 REVISION: DATE: Dimensions are in millimeters [inches] 111504 A-51 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 218 HOLES FACING UP) DESCRIPTION: OPTIONAL REMOTE MONITOR PANEL DRAWING NO: SHEET: 164201535---11 1 of 1 REVISION: DATE: Dimensions are in millimeters [inches] 111504 A-52 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 219 HOLES FACING UP) DESCRIPTION: OPTIONAL RELAY INTERFACE MODULE DRAWING NO: SHEET: 164201535---12 1 of 2 REVISION: DATE: Dimensions are in millimeters [inches] 111504 A-53 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 220 Installation Information 15–PIN D–SUB CONNECTORS DESCRIPTION: OPTIONAL RELAY INTERFACE MODULE DRAWING NO: SHEET: 164201535---12 2 of 2 REVISION: DATE: 111504 A-54 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 221 HOLES FACING UP) OPTIONAL SUPERVISORY CONTACT DESCRIPTION: MODULE DRAWING NO: SHEET: 164201535---13 1 of 1 REVISION: DATE: Dimensions are in millimeters [inches] 111504 A-55 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 222 Installation Information This page intentionally left blank. A-56 EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 223 Powerware-built battery cabinets (individually and collectively, the ”Warranted Items”) are free from defects in material and workmanship. If, in the opinion of Eaton, a Warranted Item is defective and the defect is within the terms of this Warranty, Eaton’s sole obligation will be to repair or replace such defective item (including by providing service, parts, and labor, as applicable), at the option of Eaton.
  • Page 224 Warranty This page intentionally left blank. EATON Powerware 9390 UPS (40–80 kVA) Installation and Operation Manual S 164201535 Rev E powerware.com ®...
  • Page 226 *164201535E* 164201535 E...

Table of Contents
