  • Page 1 ИБП Eaton Powerware 9390-160-N-4x0 - Установка и управление системой Sync Control для ИБП Ea Постоянная ссылка на страницу: https://eaton-power.ru/catalog/eaton-9390/9390-160-n-4x0/...
  • Page 2 ® Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Sync Control Installation and Operation Manual Installation and Operation Manual...
  • Page 4 ® Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Sync Control Installation and Operation Manual Installation and Operation Manual...
  • Page 5 Eaton and X-Slot are registered trademarks of Eaton Corporation or its subsidiaries and affiliates. National Electric Code and NEC are a registered trademarks of National Fire Protection Association, Inc. All other trademarks are property of their respective companies.

  • Page 6: Table Of Contents

    ................P-164000052 Rev 2 www.eaton.com/powerquality Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual...
  • Page 7 ..........3-21 Figure 4‐1. Typical Eaton Sync Control Block Diagram with a Eaton 9390 UPS, Eaton 9395 UPS, or 9395 SSBM....Figure 4‐2.

  • Page 8: Introduction

    Examples of this condition are two systems supplied by separate diesel generator sets, or the bypass sources for the two systems are lost. Figure 1‐1 shows the front view and Figure 1‐2 shows the interior view of the Eaton Sync Control.

  • Page 9: Conventions Used In This Manual

    The term UPS system refers to the entire power protection system – the UPS cabinet, the battery cabinet, and options or accessories installed. P-164000052 Rev 2 www.eaton.com/powerquality Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual...

  • Page 10: Safety Warnings

    Keep surroundings uncluttered, clean, and free from excess moisture. Observe all DANGER, CAUTION, and WARNING notices affixed to the inside and outside of the equipment. P-164000052 Rev 2 www.eaton.com/powerquality Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual...

  • Page 11: For More Information

    Please call the Help Desk at: 1-800-843-9433 1-919-870-3028 United States: 1-800-461-9166 ext 260 Canada: Call your local service representative All other countries: P-164000052 Rev 2 www.eaton.com/powerquality Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual...

  • Page 12: Installation Plan And Unpacking

    2.2.1 Environmental and Installation Considerations The life of the Eaton Sync Control is adversely affected if the system is not installed in a temperature and humidity controlled indoor area free of conductive contaminants. Failure to follow guidelines may void your warranty.

  • Page 13: Figure 2-1. Eaton Sync Control Dimensions - Front View

    Rear of Panel 56.9 [22.0] 64.77 [25.5] FRONT VIEW Dimensions are in millimeters [inches]. Figure 2‐1. Eaton Sync Control Dimensions – Front View P-164000052 Rev 2 www.eaton.com/powerquality Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual...

  • Page 14: Figure 2-2. Eaton Sync Control Dimensions - Side Views

    1-Inch Conduit LEFT SIDE VIEW RIGHT SIDE VIEW Dimensions are in millimeters [inches]. Figure 2‐2. Eaton Sync Control Dimensions – Side Views P-164000052 Rev 2 www.eaton.com/powerquality Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual...

  • Page 15: Eaton Sync Control Wiring Preparation

    C A U T I O N When connecting the bypass and load voltage from another model UPS to an Eaton 9390 or Eaton 9395 UPS using the Eaton Sync Control accessory, use Phase A, Phase B, and Neutral connections from the other UPS.

  • Page 16: Installation

    Only qualified service personnel (such as a licensed electrician) shall perform the electrical installation. Risk of electrical shock. Shut down all sources of power to the Eaton 9390 UPS or Eaton 9395 UPS or SSBM system before connecting the control wiring to the Eaton Sync Control enclosure and UPS. Hazardous voltages exist inside the UPS or SSBM and in the Eaton Sync Control enclosure.

  • Page 17: Figure 3-1. Typical Eaton Sync Control Wiring Terminal Locations

    C A U T I O N When connecting the bypass and load voltage from another model UPS to an Eaton 9390 UPS using the Eaton Sync Control accessory, use Phase A, Phase B, and Neutral connections from the other UPS. DO NOT connect the other model UPS Phase C bypass and load voltage to the Sync Control connection point when connecting to an Eaton 9390 UPS.
  • Page 18 On Bypass NO * Both relay Interface card (RIC) and the Industrial Relay Card (IRC) shall be set up / verified for RMP by the Eaton Field Service Engineer. Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual...

  • Page 19: Figure 3-2. Eaton Sync Control Tb1 Terminal Block Detail

    Jumper (Required if using NO contact for On Bypass signal) NOTE Any unused Building Alarm(s) may be used. Figure 3‐2. Eaton Sync Control TB1 Terminal Block Detail Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual P-164000052 Rev 2...

  • Page 20: Figure 3-3. Eaton 9390 Ups (40-80 Kva) Interface Locations For Eaton Sync Control

    INSTALLATION Mini CSB Building Alarm Terminal Block P5 Figure 3‐3. Eaton 9390 UPS (40–80 kVA) Interface Locations for Eaton Sync Control Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual P-164000052 Rev 2...

  • Page 21: Figure 3-4. Eaton 9390 Ups (100-160 Kva) Interface Locations For Eaton Sync Control

    INSTALLATION Mini CSB Building Alarm Terminal Block P5 Figure 3‐4. Eaton 9390 UPS (100–160 kVA) Interface Locations for Eaton Sync Control Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual P-164000052 Rev 2...

  • Page 22: Figure 3-5. Tb6 Terminal Block Detail

    BUILDING ALARM #4 RTN BUILDING ALARM #5 BUILDING ALARM #5 RTN BUILDING ALARM #6 BUILDING ALARM #6 RTN Figure 3‐6. Mini CSB Interface Terminals Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual P-164000052 Rev 2...

  • Page 23: Installation And Wiring With An Eaton 9395 Ups

    C A U T I O N When connecting the bypass and load voltage from another model UPS to a Eaton 9395 UPS using the Eaton Sync Control accessory, use Phase A, Phase B, and Neutral connections from the other UPS. DO NOT connect the other model UPS Phase C bypass and load voltage to the Sync Control connection point when connecting to an Eaton 9395 UPS.
  • Page 24 On Bypass NO * Both relay Interface card (RIC) and the Industrial Relay Card (IRC) shall be set up / verified for RMP by the Eaton Field Service Engineer. Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual...

  • Page 25: Figure 3-7. Eaton 9395 Ups (225-275 Kva) Interface Locations For Eaton Sync Control

    NOTE Interface connections are located in the same positions on the 9395 550/275 UPS (225-550 kVA) and the 9395 UPS (300 kVA). Figure 3‐7. Eaton 9395 UPS (225–275 kVA) Interface Locations for Eaton Sync Control 3-10 Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual P-164000052 Rev 2...

  • Page 26: Figure 3-8. Eaton 9395 Ups And Plus 1 Ups (450-550 Kva) Interface Locations For Eaton Sync Control

    NOTE Interface connections are located in the same positions on the 9395 Plus 1 UPS (225-275 kVA). Figure 3‐8. Eaton 9395 UPS and Plus 1 UPS (450–550 kVA) Interface Locations for Eaton Sync Control 3-11 Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual...

  • Page 27: Figure 3-9. Eaton 9395 Ups And Plus 1 Ups (650-825 Kva) Interface Locations For Eaton Sync Control

    (Install Relay Interface Card in any open bay.) ISBM SECTION Figure 3‐9. Eaton 9395 UPS and Plus 1 UPS (650–825 kVA) Interface Locations for Eaton Sync Control 3-12 Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual...

  • Page 28: Figure 3-10. Eaton 9395 Ups (1000-1100 Kva) Interface Locations For Eaton Sync Control

    (Install Relay Interface Card in any open bay.) ISBM SECTION Figure 3‐10. Eaton 9395 UPS (1000–1100 kVA) Interface Locations for Eaton Sync Control 3-13 Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual P-164000052 Rev 2...
  • Page 29 K4 Common – On Bypass K4 Normally Closed – On Bypass K4 Normally Open – On Bypass Strain Relief Bushing Figure 3‐12. Relay Interface Card Terminals 3-14 Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual P-164000052 Rev 2...
  • Page 30 Battery Mode J2-9 J2-10 J2-11 Alarm Mode J2-12 NOTE Maximum contact rating: 250 Vac, 30 Vdc @ 5A Wire Range: 16–24 AWG 3-15 Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual P-164000052 Rev 2...

  • Page 31: Installation And Wiring With An Eaton 9395 Sbm

    C A U T I O N When connecting the bypass and load voltage from another model UPS to a Eaton 9395 SBM using the Eaton Sync Control accessory, use Phase A, Phase B, and Phase C connections from the other UPS. DO NOT connect the other model SBM Neutral bypass and load voltage to the Sync Control connection point when connecting to an Eaton 9395 SBM.
  • Page 32 * = building Alarm 3. On 9395 SBM screen set building Alarm 3 for "No Action Taken". The default setting for Building Alarm 3 is set for "Inverters Off". 3-17 Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual P-164000052 Rev 2...

  • Page 33: Figure 3-14. Sbm Control Pan Interface Terminal Locations

    X-Slot Communication Bays (See Figure 3‐15 for detail.) and TB7 (See Figure 3‐18 for terminal assignments.) Figure 3‐14. SBM Control Pan Interface Terminal Locations 3-18 Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual P-164000052 Rev 2...

  • Page 34: Figure 3-15. Tb1 And Tb2 Interface Terminal Detail

    (See Figure 3‐17 for terminal assignments.) Figure 3‐15. TB1 and TB2 Interface Terminal Detail On Bypass Figure 3‐16. TB4 and TB5 Interface Terminal Detail 3-19 Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual P-164000052 Rev 2...

  • Page 35: Figure 3-17. Terminal Block Tb2 Connector Assignments

    All control wiring and relay and switch contacts are customer‐supplied. NOTE The building alarms can be programmed to display the alarm functional name. Figure 3‐18. Terminal Block TB3 Connector Assignments 3-20 Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual P-164000052 Rev 2...

  • Page 36: Figure 3-19. Sbm To Ups Interconnection System Control Wiring

    14 AWG (Twist Together) From UPS #3 To UPS #4 Function Note TB6-1 TB6-1 Bypass Voltage Phase B (480 Vac) 14 AWG (Twist Together) 3-21 Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual P-164000052 Rev 2...
  • Page 37 INSTALLATION This page intentionally left blank. 3-22 Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual P-164000052 Rev 2...

  • Page 38: Operating Instructions

    Chapter 4 Operating Instructions Figure This chapter describes the operation of the Eaton Sync Control with a UPS or SSBM system. Startup for UPS Systems Equipped with an Eaton Sync Control Startup and operational checks must be performed by an authorized Eaton Customer Service Engineer, or the warranty terms as specified on page 5-1 become void.

  • Page 39: Figure 4-1. Typical Eaton Sync Control Block Diagram With A Eaton 9390 Ups, Eaton 9395 Ups, Or 9395 Ssbm

    Transfer Switch Transfer Switch Figure 4‐1. Typical Eaton Sync Control Block Diagram with a Eaton 9390 UPS, Eaton 9395 UPS, or 9395 SSBM. P-164000052 Rev 2 www.eaton.com/powerquality Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual...

  • Page 40: Operation

    NOTE If either of the yellow SYNCHRONIZED TO LOAD indicators are illuminated, the PREFERRED SOURCE SELECTOR switch is locked out and the master synchronization source cannot be changed. P-164000052 Rev 2 www.eaton.com/powerquality Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual...

  • Page 41: Figure 4-3. Eaton Sync Control Controls And Indicators

    Two‐position rotary switch allowing either of the two system load buses to be assigned as the master sync source. LOAD SYNC ENABLE Enables or disables the automatic Eaton Sync Control unit. Switch is illuminated when load sync action is enabled. UPS SYSTEM-A When illuminated, indicates UPS System-A is the active master source.

  • Page 42: Maintenance Operations

    C A U T I O N Refer to the maintenance chapter in the applicable Eaton 9390 UPS, Eaton 9395 UPS or 9395 SSBM Installation and Operation Manual listed in paragraph 1.3 before beginning maintenance or repairs.
  • Page 43 OPERATING INSTRUCTIONS This page intentionally left blank. P-164000052 Rev 2 www.eaton.com/powerquality Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual...

  • Page 44: Warranty

    Eaton-built battery cabinets (individually and collectively, the ”Warranted Items”) are free from defects in material and workmanship. If, in the opinion of Eaton, a Warranted Item is defective and the defect is within the terms of this Warranty, Eaton's sole obligation will be to repair or replace such defective item (including by providing service, parts, and labor, as applicable), at the option of Eaton.
  • Page 45 WARRANTY This page intentionally left blank. P-164000052 Rev 2 www.eaton.com/powerquality Eaton 9390 UPS, 9395 UPS, and 9395 SSBM Sync Control Installation and Operation Manual...
  • Page 47 *P-1640000522* P-164000052 2...
