iPF9400S
f
Power Supply Connector
Connect the power cord to this connector.
Top Cover (Inside)
Top Cover (Inside)
a
Top Cover Roller
Prevents paper from rising when ejected.
b
Paper Alignment Line
Align paper with this line when loading it.
c
Carriage
Moves the Printhead. The carriage serves a key role in printing. (See "Carriage.")
User's Guide
Top Cover (Inside)
→P.696
