Printing Line Drawings and Text

Printing CAD Drawings

Printing CAD Drawings
Printing Line Drawings and Text .......................................................................................................................... 54

Printing Line Drawings and Text (Windows) ................................................................................................... 54

Printing Line Drawings and Text (Mac OS X) ................................................................................................. 56
Printing from AutoCAD ......................................................................................................................................... 58
Printing Line Drawings and Text
Printing Line Drawings and Text
By selecting the following Print Target from Easy Settings of the printer driver, you can easily configure setting for
printing line drawings and characters.
•
You can check the settings values for each print target by clicking View Settings.
•
Note You can also fine-tune these values as needed. ( Advanced Settings)
For details on Advanced Settings, refer to " Giving Priority to Particular Graphic Elements and Colors for Printing
Printing Line Drawings and Text (Windows)
Printing Line Drawings and Text (Windows)
This topic describes how to print line drawings based on the following example.
• Document: CAD drawing
• Page size: A3 (297.0 × 420.0 mm [11.7 × 16.5 in])
• Paper: Roll paper
• Paper type: Plain Paper
• Roll paper width: A2/A3 roll (420.0 mm [16.5 in])
1
Choose Print in the application menu.
2
Select the printer in the dialog box, and then display the printer driver dialog box.(See " Accessing the Printer
Driver Dialog Box from Applications
54
Print Target
Perspective, GIS
CAD (Color Line Drawing)
")
→P.185
Description
Settings optimized for printing 3D CAD drawings, perspective draw-
ings, and maps, including GIS maps.
Settings optimized to print intricate lines in CAD drawings clearly.
iPF9400S
".
→P.67
User's Guide
