Layout Plug-In Main Window
•
Since values entered in mm or inches are first converted temporarily to pixels and then reconverted to mm or inches,
values may be displayed that differ from the entered values.
Important
• Select Canvas Size
Selects the canvas size. If Create the Canvas at the Image Size is selected, the image size is treated as the
canvas size. It is recommended that you provide a canvas that matches the image size.
• Add Canvas Size button
Click this button to display the Add Canvas Size dialog box and register a Custom Canvas Size. (See "Add Can-
vas Size dialog box.")
• Thickness
Specifies the thickness of the canvas (the width of the canvas sides). Although you can select from 0.75 inches
(approx. 19 mm) and 1.5 inches (approx. 38 mm), you can also specify any arbitrary thickness.
•
Since values entered in mm or inches are first converted temporarily to pixels and then reconverted to mm or inches,
values may be displayed that differ from the entered values.
Important
• Amount of Extension
Selecting this check box allows you to configure the amount of extension that protrudes past the canvas sides.
This allows you to prevent white paper from appearing on the canvas sides when mounted. The larger the amount
of extension, the larger the area hidden behind the back surface.
•
Since values entered in mm or inches are first converted temporarily to pixels and then reconverted to mm or inches,
values may be displayed that differ from the entered values.
Important
• Thickness Effect
You can select from the following canvas effects.
• Image
Wraps the image to the canvas sides.
Soft Image
•
Performs Gaussian filtering on the image on the canvas sides.
• Reflection
Reflects the image on the canvas sides.
• Soft Reflection
Reflects the image on the canvas sides and performs Gaussian filtering.
• White
Makes the canvas sides white.
Black
•
Makes the canvas sides black.
• Custom Color
Makes the canvas sizes the specified color. The color is specified by clicking the Select Color button.
• Add Crop Marks
When this check box is selected, crop marks are printed at the outer edges of the image as guides to the positions
to fold the paper when mounting on a canvas.
318
• Display Information
Displays the following information.
• Input
